www.timberk.com • electrical storage water heater

9

IMPORTANT!

Never drain the appliance if water temperature is over

50°C since it may result in burns.

IMPORTANT!

The manufacturer grants an extended guarantee for

particular water heater components provided that

timely and proper routine maintenance is performed

by specialists of an authorized service centre (see the

guarantee card).

low air temperature (below 0°C), it is necessary to drain the water heater to

prevent damage of the appliance (due to water freezing in the inner tank).

To do so it is necessary to:
- disconnect the water heater from the electrical main;
- turn the water off by the cut-off valve;
- open the hot water tap and drain the system.

For SWH SE1 VO series:

- unscrew the back pressure safety valve screw and set the handle in

horizontal position; water will flow out from the pressure relieving opening

(refer to the figure 9).

For SWH SE1 VU series:

- disconnect the water heater from the water main and consumption point;

rotate it 180 degrees; water will flow out from the outlet nozzle.
It is possible not to drain the tank, but set the water heater on minimum

heating temperature with constant connection to electric supply.

3. To ensure long-term reliable operation of the water heater it is

recommended to clean the inner tank regularly and remove deposits from

the electric heating elements of the appliance as well as check condition

(fully decomposed or not) of the magnesium anode and, if necessary,

replace it with a new one in case of full decomposition.
Frequency of tank cleaning depends upon hardness of water available

in a given territory. Cleaning must be performed by special maintenance

services. You can ask the seller for the address of the nearest service

centre or find it on the website www.timberk.com.

4. Schedule maintenance should be performed under strict observance of

this instruction manual and safety precautions.
5.

The water heater is equipped with a temperature limiter (figure 10)

which cuts off power supply to the heating element upon water overheating

or its absence in the water heater. If the water heater is connected to the

electrical main, but water does not heats and the handle lamp does not

light then the temperature limiter was switched off or not switched on. To

reset the water heater to the operating condition it is necessary to:
-

unplug the water heater from the electrical main

, remove the face panel

cover;
- press the button located in the centre of the temperature limiter placed on

the heating element until it clicks;
- if the button cannot be pressed and there is no click then you should wait

until the temperature limiter cools down to the initial temperature.

Fig. 9

Fig. 10
