www.timberk.com • electrical storage water heater

7

2. To connect the water heater to the water main apply pipes with diameter

of G1/2.
3. To prevent water leakage when connecting pipes use rubber sealing

gaskets on the threaded pipe ends.
4. Screw the safety pressure valve onto the inlet nozzle marked with blue

colour and an arrow pointed water flow direction so that the water flow

direction coincides with direction of the arrow on the valve case.

5. Water heater with the mounted valve must be connected to the water

main – install a shut-off valve at the water inlet point. You need to connect

a drain pipe to the opening of the pressure relief of safety valve. Next you

should put a drain pipe to the sewer.
6. Connect a desired number of consumption points to the outlet nozzle

marked with red colour.
7. Check leak tightness of joints: open the cut-off valve and one of the outlet

valves. After the tank is filled with water, as evidenced by outflow of water

from the outlet valve, turn off the outlet valve and check leak tightness of all

the joints.

Connection to the electrical main

NOTE:

The water heater is the appliance operating in such

a manner that pressure of water in the water heater

corresponds to the pressure of water in the water main.

If pressure in the water main exceeds 0.7 MPa then it

is necessary to install a pressure reducer before the

water heater so that pressure will not exceed 0.7 MPa.

NOTE:

Do not install additional accessories, such as a cut-

off valve, between the safety pressure valve and inlet

nozzle.

IMPORTANT!

If water in the location of installation contains a large

amount of calcium, manganese or ferric salts it is

necessary to mount an appropriate filter in the supply

system to reduce the amount of boiler scale in the

tank and on the heating element.

IMPORTANT!

Prior to connecting the tank water heater make sure

that the water heater is properly grounded. Proper

grounding is important to minimize electric shocks

and risk of fire. The power cord is equipped with a

plug with a grounding pin. The appliance must be

used with a properly grounded power outlet. If the

outlet you intend to use is not properly grounded or

grounded by a time-delay fuse or a circuit breaker

address to a qualified electrician to install a proper

outlet.

1. The water heater is designed to be connected to ~220V single-phase

electrical main. Prior to connecting make sure that parameters of the

electrical main in the point of connection correspond to the parameters

specified on the identification plate with technical characteristics of the

appliance. You should observe the current electrical safety code when

installing the water heater.
2. Power outlet must be designed for rated current of 10A at least; copper-

conductor power cord must be at least 3x1.5 mm

2

 in cross-section (for

copper). The power outlet and the plug must always remain dry to prevent

current leakage. Check regularly if the power plug is tightly connected to

the outlet. Do it in the following order: insert the power plug into the outlet;

in half an hour switch off the water heater and unplug the cord; check by

your hand if the plug is heated. If the plug is heated over 50°C replace the

outlet with a new one to prevent damages, accidents and fire due to bad

electrical contact. A specialist must do this.
