12.

Electrical storage water heater

EN

1- Display
2 – Thermostat knob
3 – Position «ECO»
4 – Instant water temperature in internal tank
5 – Power supply and heating indicator
6 – heating capacity switch (depending on model can be
positioned at the bottom or side water heater cover

Open one of the demountable valves at outlet from the water heater and open the cold water

inlet valve. When water starts to freely flow out from the demountable valve, close it and insert

the plug of the power cord to the socket. When the water heater is used, the cold water inlet
valve shall be in open position.
Choose necessary heating capacity using switches situated at the cover. Right switch actuates

low capacity (800 W), left switch actuates middle capacity (1200 W), two switches together actu

-

ate high heating capacity (2000 W).

The water heating temperature in the water heater can be set in the range from +35°C to +75°C.
To increase the water heating temperature, rotate the thermostat knob clockwise. To decrease
the water heating temperature, rotate the thermostat knob counter-clockwise.
The water heater automatically maintains the set water temperature. When water temperature
in the water heater reaches the user set value, heating will be automatically stopped and the
heating indicator will extinguish. When water temperature in the water heater decreases below
the user set value, heating will be automatically activated and the heating indicator will light up
with bright pink color.

Placement of the thermostatic controller knob to the ECO position selects the mode, which cor-
responds to the most comfortable water heating temperature in the water heater (+58°C (±2°C))

and most efficient electrical energy consumption. To switch off the water heater, place the ther

-

mostat knob to the leftmost position and disconnect the water heater from the electrical mains.

CAUTION!

During heating, water may begin to drip from the port of the pressure
safety valve. Water leakage cannot be avoided and shall not be prevented,
since blocking of the valve may result in rupture of the internal tank (in
case of equipment breakdown).

6

2
3

1

4

5
