Идентификационная табличка

Data plate

Серийный номер

Serial number

1
2

3

4

5

6

7

8

11

Hz

10

9

код продукта

код продукту

product code

код завода

код заводу

code of the plant

год производства

рік виробництва

year of production

день производства

день виробництва

day of production

порядковый номер

порядковий номер

sequential number

Идентификационная табличка

Серийный номер

0000000

0000000

0

0

0

0

0

0

0

1.  Торговая марка

2.  Серийный номер или код модели

3.  Модель

4.  Материал бака

Fe+Enamel – сталь с эмалевым

покрытием

Inox – нержавеющая сталь

5.  Максимальное давление

6.  Объем

7.  Номинальная мощность

8.  Напряжение

9.  Частота тока

10. Страна-изготовитель

11. Класс защиты

1.  Brand

2.  Serial number or product code

3.  Model

4.  Tank material

Fe+Enamel - enamel steel

Inox - stainless steel

5.  Maximum pressure

6.  Volume

7.  Rated power

8.  Voltage

9.  Current frequency

10. Country of origin

11. Protection rating

33

1.  Торговая марка

2.  Серийный номер или код модели

3. Модель

4.  Материал бака

       Fe+Enamel - сталь с эмалевым

       покрытием

       Inox или Stainless Steel -

       нержавеющая сталь

5.  Максимальное давление

6. Объем

7.  Номинальная мощность

8. Напряжение

9.  Частота тока

10. Страна-изготовитель

11. Класс защиты

1.   Brand

2.   Serial number or product code

3.   Model

4.   Tank material

        Fe+Enamel - enamel steel

        Inox or Stainless Steel - stainless steel

5.    Maximum pressure

6.    Volume

7.    Rated power

8.    Voltage

9.    Current frequency

10. Country of origin

11. Protection rating

порядковый номер

sequential number

день производства

day of production

год производства

year of production

код завода

code of the plant

код продукта

product code

Before cleaning, isolate the appliance from the mains by
unplugging it or turning the switch off

10

11

12

Install the appliance on a solid wall that is not subjected to
any vibrations

Make electrical connections using cables with conductors
of suitable section

Make sure all control and protection functions operate correctly
before start the appliance

Electric shock

Excessive noise

Incorrect conductor section results in cables overheating.
It may cause fire.

Shutdown or damage of the appliance due to out-of-service
or unregulated control system operation

Before water heater handling, drain hot water

Descale the components in accordance with the instructions
provided in the applicable document. Air the room.
Work is performed in protective clothing, avoiding mixing
different products. The water heater and surrounding
objects shall be protected against ingress of cleansers

Do not use any insecticides, solvents or aggressive detergents
to clean the appliance

Burns

Injury due to contact of the skin or eyes with acidic substances,
inhalation or swallowing of harmful chemical agents.

Damage to the appliance or surrounding objects due to corrosion
caused by acidic substances

Damage to the plastic and painted parts

GENERAL SAFETY NORMS

Damage to the appliance or any objects underneath it due to the
object falling off following vibrations

Injury from an object falling off the appliance due to its vibrations

Electric shock in case of cable, plug, or socket damage

Electric shock. Burns due to the contact with overheated
components. Injuries due to the contact with sharp edges or
protrusions

Injury from the falling appliance

Damage to the appliance or any objects underneath it due to the
appliance falling off from its place of installation

Do not climb onto the appliance

Do not leave anything on top of the appliance

Do not use the water heater with a damaged power supply cable

Do not start or stop the water heater by plugging it into or out of
the wall outlet. Use the power switch for this purpose

Do not open the water heater body

Electric shock from live unsheathed wires under voltage

Ref.                               Warning                                                                              Risk                                           Symbol

1

2

3

4

5

6

7

8

9

Failure to comply with this requirement can result in severe injuries and even death

Failure to comply with this requirement can result in damage to property, plants, or animals

General requirements and safety precautions for use

Symbol                                                                               Meaning

KEY TO SYMBOLS

ADDITIONAL SAFETY RULES
