27

The installation and set-up of the water heater must be carried out by a competent person in conformity with the

applicable norms and sanitary standards in force and with any provisions set forth in this manual.

2.1. Wall-mounting

Water heater mounting is made on the main wall using brackets and fastening hooks (not included in the supply). Fastening

hooks with a diameter of at least 12 mm are recommended.

Depending on the model, you will need 2 or 4 of the fastening hooks.

The fastening must support a weight that is three times higher than the weight of the water heater filled with water.

2.1.1.

 It is not allowed to mount the vertical models horizontally, and horizontal models – vertically.

2.1.2.

The appliance should be installed as close as possible to the point of use to limit heat dispersion.

2.1.3.

 Allow for a clearance of at least 50 cm around and from the ceiling – 10 cm for maintenance activities.

2.1.4.

 Fastening of hooks to the wall must prevent inadvertent movement of the bracket of the water heater over them. After

installation, be sure to check security of the attachment.

2.1.5.

 To prevent the property of the customer and/or third party from damage caused by failures of hot water supply system

it is recommended to mount the boiler in the premises provided with waterproof floor and drainage system. Also, never put

objects sensitive to water under the boiler.

Congratulations on your purchase of an electric water heater manufactured by Ariston Thermo Group. The appliance is

designed in compliance with the European standards. It is user-friendly, demonstrates great consumer properties and

durability in operation. We hope that you will be satisfied with its work.

Please, read this manual carefully to ensure proper installation and operation of the water heater.

1. GENERAL INFORMATION

1.1. Scope of supply and correct use

1.1.1.

Water heater

1.1.2.

 Safety valve

1.1.3.

 Bracket

1.1.4.

 Installation and operation manual

1.1.5.

 Warranty certificate

1.1.6.

 Original packing

The appliance is designed for installation inside the buildings, in the household and utility premises. The appliance is intended

for water heating to a temperature below boiling point, with the option of the hot water’s utilization at several spots

(bathroom, kitchen, and toilet) and further maintenance of the set temperature in the automatic mode.

Water heating time depends on the volume of the tank and the power of the heating element.

1.2. Operating principle and main elements

Main water heater elements are as follows:

1.2.1.

 Inner tank.

1.2.2.

 Thermal insulation of polyurethane foam providing minimal heat dispersion even when the water heater power is off.

1.2.3.

 Heating element.

1.2.4.

 Temperature controller which allows you to set the desired temperature of the water heating.

1.2.5.

 Thermostat monitoring the set temperature by on/off state control of the heating element.

1.2.6.

 Safety valve which is installed at the inlet of the water heater and serves to prevent the return of water to the water line

and protect the inner tank from excessive pressure.

1.2.7.

 Magnesium anode providing additional protection for the inner tank from corrosion.

This appliance complies with the provisions set forth in the EEC/89/336 EMC directive on electromagnetic compatibility

2. INSTALLATION

TECHNICAL CHARACTERISTICS

For the technical characteristics of the water heater, please refer to the data plate located near the water inlet and outlet pipes.

                                                                                                  Ø 353

                                                                   Ø 450

Volume, l                                                           30                   40                   50                   65                  80                  50                   80                 100               120                 150

                                                                              15                    17                  19

 21                  25                  17                   22                   26                 33                    41

Steel

9,5                     -                    15                 17,5                 20                  13                   19                   22                 26                      -

Stainless steel

Weight, kg
