6.1 Internal Layout

(positioning, adjustment, removal)

Wine shelf

The shelves can be easily removed for cleaning.
Remove the bottles, completely extract the shelf,
tilt it upward until the wheels are free of their
seat and extract it.

TriMode drawer (1T, 0T, 0H)

Fixed to the slide guides with two locking nuts

>

to remove the drawer, unscrew the locking nuts

and remove the drawer.

>

to remove the inner TriMode drawer unscrew

the locking nuts.

7.1 Lighting

To provide optimum interior lighting, LED strips
illuminate the refrigerator compartment from
the top and sets of LED lights directly illuminate
different areas of the refrigerator compartment,
of the Crisper-Fresco drawers and the freezer
drawer.

In case of malfunction and/or failure of the light-
ing system, you should contact an authorized Fh-
iaba Service Agent.

Once activated, the light of the top com-
partment will automatically shut off after
6 hours.

8.1 Use of the TriMode compartment

The TriMode compartment, used in conjunction
with the Wine Cellar and Cantina compartment,
allows great flexibility in the use of the appliance.
Some possible uses:

Freezer mode

>

Liquors, such as vodka, gin, tequila, schnapps,

limoncello and the glasses to serve them

>

Rapid cooling of beverages, by activating the

bottle cooler function

>

Storage of large amounts of ice.
