INSTALLATION
1.1 UNPACKING
Remove all the protective packing
pieces. Check and respect the
appliance’s characteristics that appear
on the nameplate
(1.1.1)
.
Note the service and standard
references shown on this plate in the
boxes below for future reference.
1. 2 BUILDING INTO A BASE UNIT
Check that the air intakes and outlets are
free of obstruction
(1.2.1).
Comply with
the information concerning the fitting
dimensions (in millimetres) of the base
unit destined to receive the hob.
-
Fitting into the worktop
See diagram (
1.2.2 / 1.2.4)
- Fitting flush with the worktop
See diagram (
1.2.3 / 1.2.5
)
Except for models
Check that air circulates correctly
between the front and the back of your
hob.
If you are installing the hob above a
drawer
(1.2.6)
or above a built-in oven
(1.2.7)
, comply with the dimensions
provided on the illustrations to ensure a
sufficient air outlet at the front. Apply the
seal all around the edge of the hob
(1.2.8)
, before fitting.
Fit the hob into the base unit
(1.2.9).
If your hob is located above your
oven, the hob’s thermal safety
devices can impede the simultaneous
use of the hob and the oven’s pyrolysis
programme. Your hob is equipped with
Horizone
Play
g
i
k
an overheating prevention safety
system. This safety device can trigger,
for example, when the hob is installed
over an oven that is not sufficiently
insulated. The code «F7» then appears
in the control zone. In such
circumstances we recommend that you
increase the hob’s ventilation by creating
an opening in the side of the cabinet (8 x
5 cm).
1. 3 ELECTRICAL CONNECTIONS
These hobs must be connected
to the mains via an all-pole cut-
off device that complies with
current installation regulations. A
disconnection device must be
incorporated into the fixed wiring.
Identify the type of cable of your hob
according to the number of wires and
colours:
- 5-wire cable
(1.3.1
et
1.3.2) :
a) green/yellow, b) blue, c) brown, d)
black, e) grey.
When power is first supplied to your hob,
or after an extended power outage, an
indicator light will appear on the control
panel. Wait approximately 30 seconds or
press any key on the control panel to
make the information disappear and use
your hob (this display is normal and is
reserved for use by After-Sales Service,
where applicable). In all cases, it should
be disregarded.
Service:
Type:
