5

This appliance is not equipped with devices to remove the products of combustion. The appliance
must therefore be connected following  the norms for installation mentioned above. Special attention
must be paid to the information below regarding aeration and ventilation of the premises.

VENTILATION OF THE PREMISES

To guarantee that the appliance works correctly it is necessary that the place where the appliance is installed
is continuously ventilated. The volume of the premises must not be less than 25 m³  and the quantity of air
needed must be based on the regular combustion of gas and on the ventilation of the premises. The natural
flow of air will take place through permanent openings made in the wall of the premises to be ventilated:
these openings will be connected to the outside and must have a minimum section of 100 cm² ( see Fig. 4 ).
These openings must be made in such a way that they cannot be obstructed.

POSITION AND VENTILATION

The cooking appliances that use gas must always remove the products of combustion via a hood linked to
chimneys, chimney flues or via a direct connection to the outside ( see Fig. 4A ). If it is not possible to fit a
hood it is possible to use a fan, fitted on the window or facing directly outside, which operates when the
appliance is in use. ( see Fig. 4B ). In this way the norms in force of the country concerned regarding the
ventilation of premises are strictly followed.


CONNECTING THE APPLIANCE TO THE GAS SUPPLY

Before connecting the appliance to the gas supply you first need to remove the plastic protective plug for the
gas supply which is inserted under pressure in the gas inlet connection. To remove the plug simply unscrew
it.

Then make sure that the details shown on the label on the lower part of the case are compatible  with
those of the gas supply.
A label on the last page of this manual and on the lower part of the case  indicates the conditions for
regulating the appliance: type of gas and pressure used.
IMPORTANT: This appliance must be installed in accordance with the norms in force of the country
concerned and it must only be used in a well-ventilated place.
ATTENTION: Remember that the gas inlet connection for the appliance is  threaded 1/2 gas
cylindrical male in accordance with the norms UNI-ISO 228-1. (Fig. 6-7)

Electrical connection

The connection of the hobs to mains is effected via the flex and the three pin plug located underneath the
hotplate. The appliance operate at a main voltage of 240V a.c., frequency 50Hz. Electric power absorption is
about 800W.

WARNING: Electrical Grounding Instructions: This appliance is equipped with a (three-prong) fig.8
grounding plug for your protection against shock hazard and should be plugged directly into a
properly grounded receptable. Do not cut or remove the grounding prong from this plug.

Wiring diagrams

see Fig. 19

brown wire:

connect to L1 (hot)

blu wire:

 connect to N (neutral)

Yellow/Green wire:   connect to GND (ground)

ATTENTION: The appliance conforms with the regulations of directives 90/396EEC (Gas Directive)
regarding gas appliances for domestic use and the like, 93/68 and 73/23 (Low Voltage Directive) regarding
electrical safety and 2004/108/CE, 93/68 and 89/336 (EMC Directive) regarding electromagnetic
compatibility.


Room ventilation – Location and venting.

ATTENTION: An exhaust fan may be used with the appliance; in each case it shall be installed in
conformity with the national standards in force.
ATTENTION: Exhaust hood operation may affect other vented appliances; in each case it shall be
installed in conformity with the national standards in force.
 - CHANGING THE NOZZLES FOR USE WITH OTHER TYPES OF GAS:
