23

Cooking

level

Heat-up

Automatic time

(sec)

1

48

2

144

3

230

4

312

5

408

6

120

7

168

8

216

9

not avaible

P

not avaible

egg timer) are suspended, moreover the booster

function and heat-up automatic is stopped.

To activate this function press C, all displays (L

zone) show //. To de activate press C and arbitrary

other key within 10 sec.

• Recall function:

This feature enables recovering power levels

and timer settings after the cooktop has been

switched OFF unintendedly. For example, the

cooktop has just been switched off, the user can

switch the cooktop ON again via the ON/OFF key

(A  key) within 6 sec. Then the Pause symbol will

flash for 6 sec., now the user have to touch the

Pause symbol (C key), at this point the Recall

function becomes active. All power levels, timers

and heat-up automatics set before are recovered.

• Control Lock key :

Key lock is a functionality intended to lock the

keys during the cooktop is in operation or in pause

state. This  is useful for cleaning purposes as the

touch control is unable to differentiate a wet cloth

from a finger. When the cooktop is switched ON,

the user can touch the Key Lock (B key) for 1 sec.,

and all keys except the key Lock  and ON/OFF

are locked. When the key lock is active, press-

ing all the unlit keys (all except ON/OFF and Key

Lock) will result in a reject tone. To deactivate the

key lock, touch the Key Lock again, at this point

the cooktop can be operated regularly.

• Child Lock key :

This function is useful to protect the cooktop

against unintended operation, for example by

children. If locked, the cooktop may be turned ON,

but no cooking zone, heating level or timer may

be selected. To active this function, the user have

to power the cooktop ON, touch and hold L zone

for an arbitrary cooking zone for 3 seconds, slide

the H zone, from 0 to 9. This sequence must be

finished within 10 seconds. The display shows L

for active childlock. To disable the function: power

the cooktop ON, touch and hold L zone for 3 sec.,

then slide the H zone from 9 to 0 within 10 sec.

Now the child lock key is de.activated.

• Bridge function

  (avaible just for the octa zones):

Bridging of 2 cooking zones is the connection of

2 single cooking zones, so they can be controlled

and will behave as one large cooking zone. This

enables using cookware which has a larger bot-

tom surface than a single cooking zone. To active

this function, the user have to touch both cook-

ing zone’s simultaneously (L zone), in this way

the cooking zones are bridged, and one display

shows   , and the other the power level. To disa-

ble the bridge, the user have to touch both cook-

ing zone’s simultaneously. In this way, the cooking

zones are split into 2 separate zones again.

• Heat-up Automatic:

Heat-up automatic is a feature which enables

heating up a cold pot with full heating power and

returning automatically to the desireed cooking

level. The time during the cooking zone is heated

with full power is depending on the selected cook-

ing level. To active the Heat up automatic, you

have to hold continuous the desired cooking level

(H zone) for at least 3 sec, the display shows  .

To disable this function, touch and hold the cook-

ing zone command (L zone) for 3 sec. or select as

smaller cooking level.

EN
