English

INSTALLING THE APPLIANCE

1.  Remove the pan supports, the burner lid and

flame spreader and carefully turn the appliance upside
down and place it on a cushioned mat. Take  care  that
the  Ignition devices  and flame supervision devices
are not damaged in this operation.

2.  Apply the sponge provided around the edge of

the appliance.

3.  Do not leave a gap in the sealing agent or overlap

the thickness.

SPONGE

The thickness of the sponge is 3 mm.
The width of the sponge is 10 mm.

Do not use a silicon sealant to seal the ap-
pliance against the aperture.
This will make it difficult to remove the ap-
pliance from the aperture in future, particu-
larly if it needs to be serviced.

1.  Place the bracket (B) over the holes that match
the size ofthe screwsThere are one set of screw
holes in each corner of the hob (H).
Slightly tighten a screw (C) through the bracket (B) so
that the bracket is attached to the hob, but so that
you can still adjust the position.
2.  Carefully turn the hob back over and then gently
lower it into the aperture hole that you have cut out.
3.  On the underneath ofthe hob, adjust the brackets
into a position that is suitable for your worktop.
Then fully tighten the screws (C) to secure the hob
into position.

(A) SEALING STRIP

BOTTOM VIEW

(C) SCREW

(B) BRACKET
