ENGLISH

GB

 GENERAL

Carefully read the contents of this leaflet since it provides

important instructions regarding safety of installation, use

and maintenance.

Keep the leaflet for possible future consultation. All the

operations relating to installation/replacement (electrical

connections) must be carried out by specialised personnel

in conformity with the regulations in force.

  SAFETY WARNINGS

It is recommended to use flat-bottom pans with a diameter

equal to or slightly larger than that of the heated area. Do not

use pans with a rough base to prevent scratching the heat

surface of the cooktop (Fig.2).

This appliance is not suitable for use by children or persons

requiring supervision. Do not let children play with the ap-

pliance.

Important:

- Avoid spilling liquid, therefore to boil or heat liquids, reduce

the heat.

- Do not leave the heating elements on with empty pots and

pans or without receptacles.

- When you have finished cooking, switch off the relevant

heating element with the control indicated below.

Attention:

- Steam cleaners must not be used.

- If the surface is cracked, switch off the appliance to pre-

vent electric shock.

- This appliance is not intended for use by young children

or infirm persons without supervision.

- Young children should be supervised to ensure they do

not play with the appliance.

This appliance conforms to the European Directive EC/2002/96,

Waste Electrical and Electronic Equipment (WEEE). By making

sure that this appliance is disposed of in a suitable manner, the

user is helping to prevent potential damage to the environ-

ment or to public health.
The   symbol on the product or on the accompanying pa-

perwork indicates that the appliance should not be treated as

domestic waste, but should be delivered to a suitable electric

and electronic appliance recycling collection point.

Follow local guidelines when disposing of waste. For more

information on the treatment, re-use and recycling of this

product, please contact your local authority, domestic waste

collection service or the shop where the appliance was

purchased.

  INSTALLATION INSTRUCTIONS

These instructions address specialised installers and serve

as a guide for installation, adjustment and maintenance in

conformity with the laws and regulations in force. If a built-in

oven or any other appliance that generates heat must be fitted

directly under the glass-ceramic cooktop, THIS APPLIANCE

(oven) AND THE GLASS-CERAMIC COOKTOP MUST BE SUIT-

ABLY INSULATED in such a way that the heat generated by the

oven, measured on the bottom right of the cooktop, does not

exceed 60°C. Failure to respect this precaution may determine

improper functioning of the TOUCHCONTROL system.

Positioning

 (Fig.1)

:

The domestic appliance is designed to be built into a worktop

as illustrated in the specific figure. Apply sealant around the

entire perimeter (cut-out dimensions Fig.1B). Fix the domes-

tic appliance on the worktop by means of the 4 brackets

provided, taking the thickness of the worktop into account

(Fig.1A). If the lower part of the appliance, after installation, is

accessible via the lower part of the cabinet then it is necessary

to mount a separator panel respecting the distances indicated

(Fig.1C). If the appliance is installed with an oven underneath

then the separator is not necessary.

Electrical connections:

Before making the electrical connections, check that:

- the ground cable is 2cm longer than the other cables;

- the system ratings meet the ratings indicated on the identi-

fication plate fixed on the lower part of the worktop;

- the system is fitted with efficient earthing compliant to the

laws and regulations in force.

Earthing is obligatory by law.

If the appliance is not fitted with a cable, use type:

"H05V2V2-F"

 for a power level of up to 6400 Watts. The cross-

section of the cable should be at least 2.5 mm², or 4 mm² for

greater power levels.

The cable should never reach a temperature which is 50°C

above the temperature of the room in which it is installed.

The appliance is designed for permanent connection to the

electricity supply and should therefore be fitted with an

omnipolar switch which has a minimum opening of 3mm

between contacts. The switch should be suitable for the char-

ge indicated on the appliance data plate and must conform to

all current legislation (the yellow/green earth wire must not

be interrupted by the switch).

The omnipolar switch must be easy to reach once the instal-

lation process has been completed.

  USE AND MAINTENANCE

ATTENTION!

- The equipment has a 2800 - 3300 W power limiting system.

Please refer to the "Power Limiting" section to use this func-

tion.

- Before using the cooktop, turn on all heating plates for at least

15 minutes in 3-4 power level. This is a first-ignition process,

and must be repeated if cooktop is no used for some weeks.

Use

 (Fig.4)

:

A =

ON/OFF

button

B =

Key

 button

B1 =

key button

ON/OFF

 indicator

C =

 "-"button

D =

"+"button

E =

Heating plate selection button

E1–E3 =

Prearrangement for double or triple heating plates

F =

Double or triple heating plate selection button

F1–F3 =

 Double or triple active heating plate indicator

G =

  heating plate display

H =

Residual heat indicator

"H"

T =

Timer button

N =

Timer Display

- 19 -
