• Disconnect the appliance from the mains

supply.

• Cut off the mains electrical cable close to

the appliance and dispose of it.

3. INSTALLATION

WARNING!

Refer to Safety chapters.

3.1 Before the installation

Before you install the hob, write down the

information below from the rating plate. The

rating plate is on the bottom of the hob.

Serial number ...........................

3.2 Built-in hobs

Only use the built-in hobs after you assemble

the hob into correct built-in units and work

surfaces that align to the standards.

3.3 Attaching the seal

On-top installation

1. Clean the worktop around the cut out

area.

2. Attach the supplied 2x6 mm seal stripe to

the lower edge of the hob, along the outer

edge of the glass ceramic. Do not stretch

it. Make sure that the ends of the seal

stripe are located in the middle of one

side of the hob.

3. Add some millimetres to the length when

you cut the seal stripe.

4. Join the two ends of the seal stripe

together.

3.4 Assembly

If you install the hob under a hood, please

see the installation instructions of the hood

for the minimum distance between the

appliances.

min.
50mm

min.
500mm

If the appliance is installed above a drawer,

the hob ventilation can warm up the items

stored in the drawer during the cooking

process.

290

60 30

520

490

min. 50

270

51

min. 950

min.
12

min.
28
