9.2

Cooking zones specification

Cooking zone Nominal pow-

er (maximum

heat setting)

[W]

Power func-

tion [W]

Power func-

tion maximum

duration [min]

Cookware di-

ameter [mm]

Left front

2300

3200

10

125 - 210

Left rear

2300

3200

10

125 - 210

Right front

1400

2500

4

125 - 145

Right rear

1800

2800

10

145 - 180

The power of the cooking zones can be

different in some small range from the

data in the table. It changes with the

material and dimensions of the cookware.

For optimal cooking results use cookware

not larger than the diameter in the table.

10.

ENERGY EFFICIENCY

10.1

Product information according to EU 66/2014

Model identification

EHI6740FOK

Type of hob

Built-In Hob

Number of cooking zones

4

Heating technology

Induction

Diameter of circular cooking zones (Ø)

Left front

Left rear

Right front

Right rear

21.0 cm

21.0 cm

14.5 cm

18.0 cm

Energy consumption per cooking zone (EC

electric cooking)

Left front

Left rear

Right front

Right rear

168.6 Wh / kg

176.3 Wh / kg

178.1 Wh / kg

169.2 Wh / kg

Energy consumption of the hob (EC electric

hob)

173.1 Wh / kg

EN 60350-2 - Household electric cooking

appliances - Part 2: Hobs - Methods for

measuring performance
The energy measurements referring to the

cooking area are identified by the crosses

of the respective cooking zones.

10.2

Energy saving

You can save energy during everyday

cooking if you follow below hints.

• When you heat up water, use only the

amount you need.

• If it is possible, always put the lids on

the cookware.

• Before you activate the cooking zone

put the cookware on it.

• Put the smaller cookware on the

smaller cooking zones.

• Put the cookware directly in the centre

of the cooking zone.

• Use the residual heat to keep the food

warm or to melt it.
