INSTALLATION

CAUTION:

■

This appliance must be installed in accordance with these installation instructions.

■

This appliance shall only be serviced by authorised personnel.

■

This appliance is to be installed only by an authorised person in compliance

with the current electrical regulations and in observation of the instructions

supplied by the manufacturer.

Failure to comply with this condition will render the guarantee invalid.

■

Incorrect installation, for which the manufacturer accepts no responsibility, may

cause personal injury of damage.

■

Always disconnect the appliance from mains power supply before carrying out

any maintenance operations or repairs.

FITTING REQUIREMENTS

This cooktop can be built into a working surface 30 to 40 mm thick and 600 mm deep.

In order to install the ceramic hob into the kitchen fixture, a hole with the dimensions shown

in figure 1 has to be made, keeping in consideration the following:

■

The cooktop shall not be installed directly above a dishwasher, fridge, freezer, washing

machine or clothes dryer, as the humidity may damage the cooktop electronics.

■

If the cooktop is installed above an oven, the oven shall be provided with cooling fan.

The two appliances should be connected to the electrical supply with independent

connections.

■

IMPORTANT WARNING! This cooktop requires adequate supply of fresh, cool

air to fully function. The base of the cooktop must have direct unrestricted ven-

tilation to the room where the cooktop is installed. Follow the requirements of

figure 3 or 4.

■

There must be a distance of at least 650 mm between the hob and any wall cupboard

or extractor hood positioned immediately above (see fig. 2).

■

We would point out that the adhesive which bonds the plastic laminate to the fur-

niture must withstand temperatures not less than 150° C to avoid delamination.

■

The walls of the units must be capable of resisting temperatures of 75 °C above

room temperature.

■

Do not seal the cooktop into the benchtop with silicone or glue; this makes futu-

re servicing difficult. Delonghi will not cover the costs of removing the cooktop,

or of damage caused by this removal.

■

The walls surrounding the cooktop must be made of heat-resistant material.

■

Do not install the appliance near inflammable materials (eg. curtains).

WARNING

When correctly installed, your product meets all safety requirements laid down for

this type of product category. However special care should be taken around the un-

derneath of the appliance as this area is not designed or intended to be touched and

may contain sharp or rough edges, that may cause injury.
