take place through permanent openings made in the wall of the
premisestobeventilated:theseopeningswillbeconnectedtothe
outsideandmusthaveaminimumsectionof100cm
2
(seedig.4)
theseopeningsmustbemadeinsuchawaythattheycannotbe
obstructed.
POSITIOn And VenTILATIOn
the cooking appliances that use gas must always remove the
products of combustion via a hood linked to chimneys, chimney
luesorviaadirectconnectiontotheoutside
(seeFig.5A).Ifitisnotpossibletoitahoodit
ispossibletouseafan,ittedonthewindowor
facing directly outside, which operates when
the appliance is in use. (see Fig. 5B ). In this
way the norms in force of the country con
-
cerned regarding the ventilation of premises
arestrictlyfollowed.
Before connecting the appliance to the gas supply you irst need to remove the plastic
protectiveplugforthegassupplywhichisinsertedunderpressureinthegasinletconnec
-
tion.toremovetheplugsimplyunscrewit.
then make sure that the details shown on the label on the lower part of the case are
compatiblewiththoseofthegassupply.
A label on the last page of this manual and on the lower part of the case indicates the
conditionsforregulatingtheappliance:typeofgasandpressureused.
IMPOrTAnT:
this appliance must be installed in accordance with the
norms in force of the country concerned and It must only
beusedinawell-ventilatedplace.
ATTenTIOn:
Rememberthatthegasinletconnectionfortheappliance
is threaded 1/2 gas cylindrical male in accordance with
thenormsUNNSO228-1.(Fig.6)
table 1
Burner
typeofgas
Pressure
Nozzle
diameter
NominalCharge
ReducedCharge
mbar
1/100mm
L/h
kW
kcal/h
kW
kcal/h
Auxiliary
Naturalg20
20
74
95
1.0
$60
0.48
413
Semi-Rapid
Naturalg20
20
97
179
1.88
1617
0.73
628
Rapid
Naturalg20
20
102
190
2.0
1720
1.25
1075
triple-ring
Naturalg20
20
120
271
2.65
2451
155
1333
reGULATIOn OF BUrnerS
toregulatetheminimumontheburnerscarryoutthefollowingpro
-
cedureindicatedbelow:
1) turnontheburnerandputtheknobontopositionMINIMUM(small
lame).
2) Removetheknob(Fig.8)ofthetapwhichissetforstandardpres
-
sure.theknobisfoundonthebarofthetapitself.
3) Beside the tap bar on the work top, use a small screwdriver that
itsthescrew(gold)foundonthelowerpartofthetap(Fig.7)and
turntheixingscrewtotherightorleftuntilthelameoftheburner
isregulatedinthemostsuitablewaytoMINIMUM.
Fig.4
Fig.5a
Fig.5b
Fig.6
COnneCTIOn TO THe GAS SUPPLY
Fig.7
