•  To switch the night mode on touch the button (19)

«LIGHT  », the symbol (21) «

 » will light up on

the display (7). To switch the illumination off touch the

button (19) «LIGHT  » again, the symbol (21) «

» will go out.

TIMeR OPeRATIOn SeTTInG «TIMeR  »

•  Consequently press/touch the button (14) «TIMER

» to set up the timer within the range from 1 to 12

hours with 1 hour step, the timer operation time will

be shown on the display (7) with the digital symbols

(17).

•

After the preset operation time runs out, the air

humidifier will be switched off.

•  To switch the timer off press/touch the button (20)

«TIMER  » until the digital symbols (17) «Co»

appear on the display (7).

•

Note:

 — to view the preset timer operation time

touch/press the button (14), the preset time will be

shown on the display (7) with digital symbols (17).

LOW WATeR LeveL InDICATIOn

•  When the water tank (3) becomes empty, the air

humidifier will switch off, you will hear a sound signal

and the symbol «

» will appear on the display (7).

•  Switch the unit off with the button (10) «ON/OFF

», remove the nozzle (1), remove the water tank (3)

taking it by the handle (2). Unscrew the lid and fill

the water tank (3) with water, screw the lid. Place the

filled water tank (3) on the air humidifier body and

•

Hard water causes the appearance of mineral scale

inside the process chamber, on the sprayer and in

the water tank (3); mineral scale leads to improper

operation of the humidifier.

•  It is recommended to clean the process chamber and

the sprayer weekly, and to change water in the water

tank (3).

•  If you are not going to use the air humidifier for a

long time:

•  Clean the cartridge filter after passing of about 200

l water through it, and if using hard water or a white

deposit appears on the furniture, more often.

•  Remove the nozzle (1), take the water tank (3) by the

handle (2) and remove it from the air humidifier body.

•  Turn over the water tank (3), unscrew the lid rotating

it counterclockwise and remove it, remove the

cartridge filter, rotating it counterclockwise.

•  Put the cartridge filter into a container with table

vinegar for 15-20 minutes, take the filter out and

wash it thoroughly under a warm water jet.

•  Install the cartridge filter on the lid rotating it

clockwise.

CLeAnInG THe AIR FILTeR

•  Press the air filter grid (8) clamp and remove the grid.

•  Clean the filter from the dust and install the grid (8)

with the filter back to its place.

STORAGe

•  Clean the air humidifier before taking it away for

storage, make sure that the air humidifier parts are

dry, pack the air humidifier in the original package.

•  Do not store the unit with wet cartridge filter,

remaining water in the tank (3) and the process

chamber.

•  Keep the air humidifier in a dry cool place out of

reach of children and disabled persons.

WARnInG!

Always switch the air humidifier off and unplug it

before maintenance works or cleaning.

then install the nozzle (1).

•  Switch the air humidifier on and set the required

operation modes.

AIR AROMATIzATIOn FUnCTIOn

•  If you want to use the aromatization function, remove

the container (9) and add some drops of water-

soluble aromatic oil into it, install the container back

to its place.

•

Notes:

 - use water-soluble aromatic oils only

 - if you are not going to use the aromatization

function, remove the container, wash it with water,

dry and install back to its place

CLeAnInG AnD MAInTenAnCe

 -

pour the water out of the water tank (3) and the

process chamber;

 - wash and clean the process chamber and the

sprayer;

 -

wash the water tank (3);

 -

dry the air humidifier thoroughly and take it away

for storage.

WeekLY CARe

•  Once a week wash the water tank (3), the process

chamber and the sprayer with warm water and

neutral detergent and rinse thoroughly with water.

•

Add some detergent drops on the sprayer and wait

for several minutes. Remove the deposits from the

sprayer surface with a brush.

•

Note:

 — you can use citric acid solution to clean the

process chamber (8) and the sprayer (11).

•  Wipe the air humidifier body with a soft, slightly damp

cloth and then wipe it dry.

•  Do not immerse the air humidifier body, the power

cord (5) and the power plug into water or any other

liquids. Provide that no liquid gets inside the air

humidifier body.

•

do not use solvents or abrasives to clean the surface

of the air humidifier body and the water tank (3).

CLeAnInG THe CARTRIDGe FILTeR (6)

•  The cartridge filter softens water, removes

unpleasant smells and prevents generation of

bacteria.
