www.timberk.com • electric air washer (purifier)

3

•  Do not allow rain drops contact the device, do not use it in excessively humid
rooms (bathroom, laundry room, sauna, etc.).

•  The device must be in a vertical position.

•  Do not sit, stand or put heavy things on the device.

•  Using such additives for water as for example essential oils, aromatic fluids,
detergents, etc., damage the material of the tank and the device on the whole.
Any use of such additives relieves the manufacturer/seller from any warranty
obligations.

The manufacturer reserves the right to change the set-list of the device
(including liquid and powder components) for different supplies without prior
notice. The changes either in no way influence the basic technical parameters
of the device or may improve them, and also not violate the legislation or quality
standards of the countries of manufacture, transit and selling.

The changes in the set-list may result in changing of the weight and dimensions
of the device, but not more than by +\- 5-20% (depending on the product
category).

3. TECHNICAL CHARACTERISTICS

Table 1

Discription

Unit

TAW H6 D

Capacity of humidity

ml/h

200

Power supply

V/Hz

220~/50

Water tank

L

2

Rated power consumption

W

25

Rated current

А

0,08

Protection class

-

IPXO

Electrical protection class

-

 II

Service area

m

2

25

Air flow

m

3

/hr

120

Net weight

kg

2,9

Device dimensions

mm

260x260x340

•  Prior to using the device, read operation guidelines carefully.

•  The device must be out of reach of children. Do not allow children to play with
the device. Never leave a child without supervision near the operating device.

•  Do not use the device with a damaged power cord or a plug. Do not use the
device if it was damaged or fell down. Return it for inspection, adjustment or
repairs to a service center.

•  The device must be installed on a hard, flat and horizontal surface.

•  Install the device in such a place, where the risk of contacting or hitting it is
minimal.

•  The device needs regular cleaning. See operation manual section
«Recommendations on maintenance of the device».

•  Do not submerge the device in water; use only clean damp cloth to clean its
case. Do not use abrasive detergents or solvents for cleaning.

•  Use the device only fully assembled.

•  Always disconnect the device from the mains prior to moving it and filling
its tank, draining water, cleaning, maintenance, assembly-disassembly of
particular units or if you do not use the device for a long time.

•  Do not pull the cord to disconnect the device from a socket. To disconnect
the device from the mains take its plug directly. Do not disconnect the device
from the mains with wet hands.

•  Do not allow foreign objects get into the device, it may result in mechanical
damages and short circuit. Do not block air inlet/outlet holes.

•  Never lay the cord under carpets, as well as do not put it on sharp or hot
things. Make sure the cord does not bend and no one walks on it.

•  Electrical appliances must be repaired only by authorized servicing personnel.
Improper or incompetent repairs may lead to accidents and injuries.

•  If the power cord is damaged then it must be immediately replaced by a new
one by competent personnel to avoid electric shock and fire.

•  The device is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or a lack of experience and
knowledge, unless they have been given supervision or instruction concerning
the use of the device by an individual responsible for their safety.

•  Do not use the device outdoors.

•  Do not use the device for purposes it is not intended for.

•  This device is intended only for domestic use.

•  Do not use the device in a room where there are combustible gases and
evaporations.
