Sencor SSI3520RS - Инструкция по эксплуатации - Страница 6

- 6 -

02/2021

 Copyright © 2021, Fast ČR, a.s.

Attention:

Do not use the steam function for silk and synthetics so as not to

damage the fabric.

WATER SPRAYING FUNCTION

 ■

The water spraying function can be used with any ironing method. It serves to

moisten the fabric and effectively helps with ironing heavily crumpled textiles.

 ■

Make sure that there is a sufficient amount of water in the water tank and turn the

iron so that its front side points towards the location that you wish to spray.

 ■

Press the water spraying button ( ). Water will spray out of the nozzle on the front

side.

Note:

When using the water spraying function for the first time or when you

have not used the iron for a  long time, it will be necessary to press the

water spraying button several times before the nozzle starts working

correctly.

DRIP-STOP SYSTEM

The iron is equipped with the Drip-Stop system, which automatically stops water

supply when the set temperature is insufficient for generating steam and thereby

prevents potential dripping of hot water out of the steam outlets.

ANTI-CALC SYSTEM

This iron is equipped with a permanent Anti- Calc filter, which limits the formation of

limescale deposits inside the iron. This filter cannot be deactivated. The effectiveness

of the filter depends on the hardness of the water used.

AUTOMATIC SHUT-OFF FUNCTION

 ■

The iron will shut off automatically when left 8 minutes without movement in the

upright position, or after 30 seconds without movement in the horizontal position

or when tilted over on one of its sides.

Attention:

Despite the iron being equipped with an automatic shut-off

function, for safety reasons, never leave it without supervision

when it is connected to a mains power socket.

TURNING OFF

 ■

When you have finished using the iron, stand it upright. Set the steam release
regulator to position

 (steam release off ). This will deactivate the steam function.

 ■

Set the temperature control knob to the MIN position.

 ■

Disconnect the power cord from the power socket and allow the soleplate to

cool down. After the soleplate has cooled down, clean the iron according to the

instructions in chapter Cleaning and maintenance.

TIPS FOR QUALITY IRONING

 ■

When the drum of the washing machine is overfilled with a large amount of laundry,

the laundry may become excessively crumpled, making it harder to iron. Try filling

the washing machine with a  smaller amount of laundry or set a  lower spinning

speed.

 ■

If you are ironing fabrics from blended materials (e.g. 40 % wool and 60 % synthetic

material), set the temperature according to the material which is ironed at a lower

temperature.

 ■

If you do not know the composition of the fabric, identify the suitable temperature

setting by ironing a  piece of the fabric from the underside. Start by setting a  low

temperature and gradually increase it until the ideal temperatures is achieved.

 ■

Never iron over places that have sweat marks or other stains. The high temperature

fixes the stain in place, making it difficult to remove.

 ■

To avoid silk, wool and synthetic fabrics from being shiny after ironing, iron them

from the underside.

 ■

Some materials are easier to iron when they are lightly damp.

 ■

Spray fine fabrics before ironing them or iron them under a  lightly dampened

wiping cloth.

CLEANING AND MAINTENANCE

CLEANING AFTER EVERY USE

 ■

Before cleaning it, turn the iron off according to the instructions described

previously. The iron must be disconnected from the power socket and cooled down.

Open the water tank cap and then empty out the remaining contents of the water

tank over a sink. Close the cap again.

 ■

In the event that the soleplate or the surface of the iron is dirty, wipe with a lightly

dampened cloth and then wipe dry.

 ■

For cleaning, do not use steel wool, solvents or cleaning products with an abrasive

effect, etc. to prevent damaging the surface being cleaned. Do not submerge the

iron in water when cleaning it.

REMOVING LIMESCALE DEPOSITS

 ■

For the removal of limescale deposits from the inner part of the soleplate, the iron

is equipped with a Self-Cleaning function. Use this function regularly at least once

every 14 days.

 ■

Disconnect the iron from the power socket and set the steam release regulator to
position

 (steam release off ).

 ■

Fill the water tank with clean water up to the maximum water level mark. Connect

the iron to a  power socket and set the temperature control knob to the MAX

position. Wait until the heating indicator turns off. Then disconnect the iron from

the power supply again.

 ■

Hold the iron in a  horizontal position above the sink. Press the Self-Clean button

A14

 and hold it down. Steam and hot water will start to be released from the

soleplate. At the same time also limescale deposits from the inner parts of the

soleplate will be removed. Tilt the iron from side to side several times until the water

tank is completely emptied out. After emptying it out, release the button

A14

. You

may repeat this process once more if necessary.

 ■

Connect the iron to a  power socket and allow it to heat up once more to the

maximum temperature in order to dry out the soleplate. Iron over a  piece of

unneeded fabric to remove any water stains that may have formed on the soleplate

during the cleaning process. Unplug the iron from the power socket and allow it

to cool down.

STORAGE

 ■

After you have finished ironing, pour out any unused water from the water tank

(careful, it may be hot), or allow it to evaporate if necessary and allow the iron to cool
down. Set the steam release regulator to position

 (steam release off ). Wind the

power cord around the stand, making sure that the power cord is not touching the

soleplate, and then stand the iron on the stand

A8

.

Attention:

Keep the stored iron away from extreme temperatures, direct

sunlight and excessive humidity and do not store it in an overly

dusty environment. Do not place anything on to the stored iron.

TECHNICAL SPECIFICATIONS

Rated voltage range  .................................................................................................... 220−240 V AC

Rated frequency........................................................................................................................50/60 Hz

Rated power input ........................................................................................................ 2.600-3.100 W

Continuous steam output .................................................................................................... 35 g/min

Steam impulse ........................................................................................................................170 g/min

Water tank capacity  ................................................................................................................... 280 ml

Dimensions (length × width × height) ................................... 300 mm × 125 mm × 135 mm

Weight ................................................................................................................................................1.2 kg

Changes to text and technical parameters are reserved.

INSTRUCTIONS AND INFORMATION REGARDING THE

DISPOSAL OF USED PACKAGING MATERIALS

Dispose of used packaging material at a site designated for waste in your municipality.

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC

EQUIPMENT

This symbol on products or original documents means that used

electric or electronic products must not be added to ordinary

municipal waste. For proper disposal, renewal and recycling, hand

these products over to determined collection points. Alternatively, in

some European Union states or other European countries you may

return your appliances to the local retailer when buying an equivalent

new appliance.

Correct disposal of this product helps save valuable natural resources

and prevents potential negative effects on the environment and human health, which

could result from improper waste disposal. Ask your local authorities or collection

facility for more details.

In accordance with national regulations penalties may be imposed for the incorrect

disposal of this type of waste.

For business entities in European Union states

If you want to dispose of electric or electronic devices, ask your retailer or supplier for

the necessary information.

Disposal in other countries outside the European Union.

This symbol is valid in the European Union. If you wish to dispose of this product,

request the necessary information about the correct disposal method from the local

council or from your retailer.

This product meets all the basic requirements of EU directives related to

it.
