EN

GETTING STARTED

1.  Before first use.

Remove all adhesive remains and

gently rub with a dampened cloth. Position the steam

generator iron horizontally on the ironing-board or

on a heat resistant, secure surface at the same height

as an ironing-board. Unwind and straighten the

power cord and the steam cord. When turned on for

the first time, temporary vapours/odours may occur.

2.  Open the water tank lid.

 Fill the water tank using

cold water. It is recommended to use Electrolux

AquaSense filtered water, taking out impurities like

limescale. Otherwise use destilled water. If the tap

water is particularly hard, use a mix of 50% destilled

water and 50% tap water. Empty the water tank to

rinse out any foreign particles which may remain

from the manufacturing process.

3.  Always refill the water tank

to MAX level using cold

water (A). Replace the water tank lid.

 Caution!

Never operate the appliance without any

water in the tank.

4.  Connect the steam generator iron

to the mains

supply. Turn the power knob (A) clockwise to MAX.

Turn the temperature selector clockwise to maximum

setting (B).

The temperature indicator light on the iron will

illuminate. Then, select a steam level by turning the

steam level control knob

 between low - medium - high

steam (C).

5.  The steam generator is equipped with ECO setting.

Ironing on ECO setting

( ECO setting needs to be selected

on both temperature dial and control panel)

instead of

MAX setting saves up to 20 % energy consumption. ECO

setting is using lower pressure, producing lower steam

rate but delivering faster heat-up time.

6.

When the temperature indicator light turns on, the

steam station is pre-heating. When the light turns off, it

is ready to be used. Press and hold the steam button for

some seconds to get steam. Then hold for a few more

seconds in order to clean the steam generating system.

7.  Iron an old towel,

to ensure that any residues inside

the iron are not transferred to the laundry.

If necessary, wipe the soleplate with a slightly damp

cloth.

OPERATING INSTRUCTIONS

8.  To activate the steam function,

press the steam

button for 3-5 seconds, release the button to eject

a concentrated jet of steam. When releasing the

button, use up the steam before putting it back on

the iron rest of the steam station. It is recommended

that the steam button is used for short periods.

Caution!

Never release steam while the iron is

standing on its rest.

9.  Continuous (AUTO) steam function:

Press and hold

the steam button, and move the steam activation

slider forward, to lock the steam button. Release

both buttons. A jet steam will eject continuously and

steadily (AUTO STEAM). To unlock the steam button

and stop the continuous jet steam, press the steam

activation slider backwards.

10. Turn off the iron

by turning the power knob

counterclockwise.

11. Always cool the iron

 fully on the iron rest before

stowing away. Once the iron is cool, empty the water

tank. Store the steam generator iron

12. Always store the cord

by the cord storage on the

generator base. NEVER wind the power cord around

the iron.

CLEANING

13. Always store iron on its heel rest.

To clean exterior surfaces, use a damp soft cloth and

wipe dry.

Caution:

 Do not use any chemical solvents, as these

will damage the surface.

14. Position the appliance so that the boiler safety cap

is uppermost.

Remove the rubber cover, unscrew

the boiler safety cap using the flat key enclosed in

the bottom. Turn the appliance upside-down over a

sink and completely empty the boiler. Mix a descaler

agent and water at the specified ratio, prepare at least

300ml descaler mixture. (Use recommended ratio for

the mixture, if there is much scaling, properly increase

the proportion of descaler.)

Note: We recommend to use the descaler EUD5 from

Electrolux. Please follow the water/ descaler liquid

ratio instructions on the bottle. We recommend to

clean the product every 2 months.

15. Fill the mixture into the boiler and tighten the

boiler safety cap.

 Soak for one to two hours under

room temperature (increase the soaking time if

necessary; max 8 hours). Pour out the mixture. Fill the

boiler with clean water, then pour it out. Repeat this

step for several times until the scales are removed

and there is no longer a descaler smell. Place back

one measuring cup of clean water in the boiler before

reassembling.

THE WARRANTY DOES NOT COVER DAMAGE

CAUSED BY CLOGGING DUE TO LIME.

Once cleaning

is done, do not keep the boiler completely empty but

leave some water still there (before closing it again).

16. When finished using the appliance,

turn the

temperature dial to the OFF

(“MIN“)

 position. Store

the iron on the iron rest.

Note: Do not store the iron with water in the tank.
