background image

1

DESCRIPTION

1.1

PURPOSE

This machine is used to cut grass, light weeds, and other
similar vegetation at or around ground level. The cutting
plane must be approximately parallel to the ground surface.
You cannot use the machine to cut or chop hedges, shrubs,
bushes, flowers and compost.

1.2

OVERVIEW

Figure 1 - 20.

1

Battery release button

2

On/off button

3

Speed button

4

Lock-out button

5

Trigger

6

Auxiliary handle

7

Upper shaft

8

Coupler

9

Lower shaft

10

Trimmer head

11

Cut-off blade

12

Guard

13

Screw

14

Release button

15

Positioning hole

16

Knob

17

Cap

18

Lower support

19

Tab

20

Spool cover

21

Spool housing

22

Spool

23

Line exist hole

24

Slot

25

Angle transmission hole

26

Metal rod

27

Nut

28

Outer cup

29

Blade

A

Direction of roatation

B

Best cutting area

C

Dangerous cutting area

2

SAFETY



WARNING

Make sure that you follow all safety instructions.

Refer to Safety Manual.

3

INSTALLATION

3.1

UNPACK THE MACHINE



WARNING

Make sure that you correctly assemble the machine before
use.



WARNING

If parts of the machine are damaged, do not use the
machine.

If you do not have all the parts, do not operate the
machine.

If parts are damaged or missing, contact the service
center.

1. Open the package.
2. Read the documentation provided in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and packing material in compliance with

local regulations.

3.2

ATTACH THE GUARD

Figure 2.



WARNING

Do not touch the cut-off blade.

1. Remove the screws from the trimmer head with a Phillips

head screwdriver (not included).

2. Put the guard onto the trimmer head.
3. Align the screw holes on the guard with the screw holes

on the trimmer head.

4. Tighten the screws.

3.3

ASSEMBLE THE SHAFT

Figure 3.

1. Loosen the screw on the coupler.
2. Push in the release button on the lower shaft.
3. Align the release button with the positioning hole and

slide the two shafts.

4. Turn the lower shaft until the button locks into the

positioning hole.

5. Tighten the screw with the hex wrench.

3.4

ATTACH THE AUXILIARY

HANDLE

Figure 4.

4

English
