9

English

Attaching the Auxiliary Handle (Fig. A, C)

1.  Place the auxiliary handle

 6

 on top of the upper powerhead

pole

 19

.

2.  Place the handle barrier

 17

 under the auxiliary handle

 6

 and

upper powerhead pole

 19

 so the upper powerhead pole

 19

is sandwiched between two handle pieces.

nOTE:

 Before assembling further, take care to align the

key

 34

 on the handle barrier

 17

 with the key slot

 35

 on the

underside of the upper powerhead pole

 19

.

Inserting and Removing the Battery Pack
from the Tool (Fig. B)

nOTE:

 Make sure your battery pack

 8

 is fully charged.

To Install the Battery Pack into the Tool Handle

1.  Align the battery pack

 8

 with the rails inside the tool’s

handle (Fig. B).

2.  Slide it into the handle until the battery pack is firmly seated

in the tool and ensure that you hear the lock snap into place.

To Remove the Battery Pack from the Tool

1.  Press the release button

 9

 and firmly pull the battery pack

out of the tool handle.

2.  Insert battery pack into the charger as described in the

charger section of this manual.

Fuel Gauge Battery Packs (Fig. B)

Some

D

e

WALT

 battery packs include a fuel gauge which

consists of three green LED lights that indicate the level of
charge remaining in the battery pack.
To actuate the fuel gauge

 14

 , press and hold the fuel gauge

button. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to be recharged.

nOTE:

The fuel gauge is only an indication of the charge left on

the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end‑user application.

ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories.

An accidental

start‑up can cause injury.

WARNING:

 Use only

D

e

WALT

 battery packs and chargers.

•

Young children and the infirm.

 This appliance is not

intended for use by young children or infirm persons
without supervision.

•  This product is not intended for use by persons (including

children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with this product.

Description (Fig. A, E)

WARNING:

Never modify the area light. Damage or

personal injury could result.

1

Variable speed trigger

2

Lock‑off lever

3

Lock‑off tab

4

Powerhead handle

5

Speed control switch

6

Auxiliary handle

7

Strap mount

8

Shoulder strap (Fig. F)

Intended Use

This powerhead has been designed for powering

D

e

WALT

attachement capable heads. DO NOT use this tool for any job
other than its intended use.

DO nOT

use under wet conditions or in the presence of

flammable liquids or gases.

DO nOT

 let children come into contact with the tool.

Supervision is required when inexperienced operators use
this tool.

Date Code Position (Fig. B)

The date code

 13

, which also includes

the year of manufacture,

is printed into the housing.
Example:

2020 XX XX

Year and week of Manufacture

 Wear ear protection.

 No hands

Wear slip‑resistant footwear.

Wear slip‑resistant gloves.

Wear head protection.

Do not expose the tool to rain or high humidity or leave
outdoors while it is raining.

Switch the tool off. Before performing any maintenance
on the tool, remove the battery from the tool.

Keep bystanders away.
