Meaning of the Indication Elements

(AL 1830 CV/AL 1880 CV)

(Fast) Flashing of the Green Battery Charge Indicator

The rapid-charging procedure is indicated by

fast flashing

 of the

green

 battery charge in-

dicator .

Note:

 The rapid-charging procedure is only possible when

the battery temperature is within the allowable charging

temperature range, see section “Technical Data”.

(Slow) Flashing of the Green Battery Charge Indicator

When the charging condition of the battery is

80%, the

green

 battery charge indicator

flashes slowly

.

The battery can be removed for immediate use.

Continuous Lighting of the Green Battery Charge

Indicator

Full

Continuous lighting

of the

green

 battery

charge indicator indicates that the battery is

fully charged.
When the battery is not inserted,

continuous lighting

 of the

battery charge indicator indicates that the mains plug is in-

serted in the socket outlet and that the battery charger is

ready for operation.

Continuous Lighting of the Red Battery Charge Indicator

Continuous lighting

 of the

red

 battery charge

indicator indicates that the temperature of the

battery is not within the allowable charging temperature

range, see section “Technical Data”. As soon as the allowable

charging temperature range is reached, the battery charger

automatically switches to rapid charging.

Flashing Red Battery Charge Indicator

A

flashing red

 battery charge indicator indic-

ates a different malfunction of the charging

procedure, see section “Troubleshooting – Causes and Cor-

rective Measures”.

Operation

Switching On and Off (see figure H)

To

switch on,

 firstly press the lock-off button

(3)

. Then

press the On/Off switch

(4)

 and keep it pressed.

To

switch off,

 release the On/Off switch

(4)

.

Lawn Trimming/Edge Cutting (see figure I)

Turn the handle against the shaft by 180° to position the

trimmer head either for lawn trimming or edge cutting. Re-

lease button

(2)

 so that the turning mechanism engages.

Now, turn the complete machine to the working position.

Lawn trimming

Move the trimmer left and right, keeping it well away from

the body. Cut higher grass in steps.

Edge cutting

Guide the trimmer along the edge of the lawn. Avoid contact

with solid surfaces or walls to prevent rapid wear of the cut-

ting line.

Cutting around trees and bushes

Carefully cut around trees and bushes so that they do not

come into contact with the cutting line. Plants can die if you

damage the bark.

Dismounting the spool, winding up the cutting

line and mounting the spool (see figures J to L)

u

Remove the battery before replacing the spool.

Press both latches of the spool cover together and remove

the spool cover

(11)

. Afterwards, remove the empty spool

(12)

.

Cut off approx. 4.0 m line from the refill roll. Slide one end of

the cutting line into the hole for line wind-up

(13)

 in the

spool and wind up the cutting line uniformly and tightly.
Slide the other end of the cutting line through the hole for

line guiding

(14)

 in the trimmer head and mount the spool

back into the trimmer head. Affix the spool by mounting the

spool cover

(11)

.

Line Feeding (see figure M)

Semi-automatic Line Feeding

The trimmer is equipped with a semi-automatic feeding sys-

tem. The system feeds 10 mm of the line with every press of

the on/off switch

(4)

.

Manual Line Feeding

Press the line-feed button

(15)

, and pull the cutting line out

to the desired length.

Troubleshooting

d.c.

Lawn Trimmer/Lawn Edge Trimmer

Problem

Possible Cause

Corrective Action

Motor refuses to start Battery discharged

Recharge battery

Battery too hot/cold

Allow to cool/warm
