 | English

Action

Figure

Page

Mounting the protection guard

F

440

Battery charging and inserting

G

440

Switching On and Off

H

441

Switching from lawn trimming/

edge cutting

I

442

Removing the line spool

J

443

Winding line on spool

K

443

Mounting the line spool

L

444

Line feeding

M

444

Maintenance, Cleaning and Stor-

age

N

445

Accessories

O

446

Assembly

u

Caution: Switch the garden tool off and remove the

battery before performing any maintenance.

Connect shaft (see figures C and D)

Note:

A connected shaft can no longer be dismounted.

Remove the transport safety

(9)

.

Connect the individual parts of the shaft until they can be

heard to engage.

Mounting and adjusting the handle (see figure E)

The handle

(1)

 can be set to different positions. To change

the adjustment, press buttons

(7)

 and move the handle to

the desired position. Release the buttons

(7)

 again so that

the handle can engage.

Mounting the protection guard (see figure F)

Position the protection guard

(8)

 on the trimmer head and

fasten it with the provided screw.

Switching on

u

Caution: Switch garden tool off and remove battery

from machine before adjusting or cleaning.

u

The cutting line continues to rotate for a few seconds

after the trimmer is switched off. Allow the motor/cut-

ting line to stop rotating before switching on again.

u

Do not briefly switch off and on again several times in

a row.

u

Only use Bosch approved cutting elements. Cutting

performance will vary with different cutting elements.

Charging the Battery

u

Observe the correct mains voltage! The voltage of the

power supply must correspond with the data given on

the nameplate of the battery charger. Battery char-

gers marked with 230 V can also be operated with 220

V.

The battery is equipped with temperature monitoring that al-

lows charging only in the temperature range between 0 °C

and 45 °C. In this manner, a high battery service life is

achieved.

Note:

The battery is supplied partially charged. To ensure

full battery capacity, completely charge the battery in the

battery charger before using for the first time.
The lithium-ion battery can be charged at any time without

reducing its service life. Interrupting the charging procedure

does not damage the battery.
The “Electronic Cell Protection (ECP)” protects the lithium-

ion battery against deep discharging. When the battery is

discharged, the machine is switched off by means of a pro-

tective circuit: The garden product no longer operates.

Do not continue to press the On/Off switch after an auto-

matic shut-off of the machine.

 The battery can be dam-

aged.
Observe the notes for disposal of the battery.

Inserting/Removing the Battery (see figure G)

Note:

 Using unsuitable batteries can lead to malfunctions or

damage the machine.
Insert the charged battery

(6)

. Ensure the battery is inserted

correctly.
To remove the battery

(6)

 from the machine, press the bat-

tery unlocking button

(5)

 and pull the battery out.

Charging Procedure

The charging procedure starts as soon as the mains plug of

the charger is plugged into a socket outlet and the battery

(6)

 is inserted onto the charger

(10)

.

Due to the intelligent charging method, the charging condi-

tion of the battery is automatically detected and the battery

is charged with the optimum charging current, depending on

battery temperature and voltage.
This gives longer life to the battery and always leaves it fully

charged when kept in the charger for storage.

Understanding the Indicators (AL 1815 CV)

Flashing battery charge indicator

The charging process is indicated by the

flash-

ing

 of the battery charge indicator .

Continuous lighting of the battery charge indicator

Full

Continuous lighting

 of the battery charge in-

dicator indicates that the battery is fully

charged or that the temperature of the battery is not within

the allowable charging temperature range, and cannot be

charged for this reason. The battery is charged as soon as

the allowable charging temperature range is reached.
When the battery is not inserted,

continuous lighting

 of the

battery charge indicator indicates that the mains plug is in-

serted in the socket outlet and that the battery charger is

ready for operation.
