u

  Remove the empty spool (23) from the housing.

u

  Remove any dirt and grass from the spool cover and

housing.

u

  Take the new spool and push it onto the boss in the

housing. Rotate the spool slightly until it is seated.

u

  Unclip the end of the cutting line and guide the line into

the eyelet (24). The line should protrude approx. 11 cm

from the spool cover.

u

  Align the tabs (21) on the spool cover with the cut outs

(25) in the housing.

u

  Push the cover onto the housing until it snaps securely

into place.

Warning!

 If the cutting lines protrude beyond the trimming

blade (26), cut them off so that they just reach the blade.

You may wind new cutting line onto an empty spool.

u

  Remove the empty spool from the tool as described

above.

u

  Remove any remaining cutting line from the spool.

u

  Feed 2 cm of cutting line into the hole (27) in the spool as

u

  Bend the cutting line and anchor it in the L-shaped slot

(28).

u

  Wind the cutting line onto the spool in the direction of the

arrow. Make sure to wind the line on neatly and in layers.

u

  When the wound cutting line reaches the recesses (29),

cut the line. Let the line protrude approx. 12 cm from the

O).

u

Warning!

 Only use the appropriate type of BLACK+DECKER

cutting line.

Troubleshooting

If your tool seems not to operate properly, follow the

instructions below. If this does not solve the problem, please

contact your local BLACK+DECKER repair agent.

Warning!

 Before proceeding, unplug the tool.

Appliance runs slowly

u

  Check that the spool housing can rotate freely. Carefully

clean it if necessary.

u

  Check that the cutting line does not protrude more than

11 cm from the spool housing. If it does, cut it off so that it

just reaches the line trimming blade.

Automatic line feed does not work

u

  Keep the tabs depressed and remove the spool cover

from the housing.

u

  Pull the cutting line until it protrudes 11 cm from the

install a new spool of cutting line as instructed above.

u

  Align the tabs on the spool cover with the cut outs in the

housing.

u

  Push the cover onto the housing until it snaps securely

into place.

u

  If the cutting line protrudes beyond the trimming blade, cut

it off so that it just reaches the blade.

If the automatic line feed still does not work or the

spool is jammed, try the following suggestions:

u

  Carefully clean the spool cover and housing.

u

  Remove the spool and check if the lever can move freely.

u

  Remove the spool and unwind the cutting line, then wind it

on neatly again as described above. Replace the spool as

instructed.

Maintenance

Your BLACK+DECKER corded/cordless appliance/tool has

been designed to operate over a long period of time with a

minimum of maintenance. Continuous satisfactory operation

depends upon proper tool/appliance care and regular

cleaning.

Your charger does not require any maintenance apart from

regular cleaning.

Warning!

 Before performing any maintenance on corded/

cordless power tools:

u

  Switch off and unplug the appliance/tool.

u

  Or switch off and remove the battery from the appliance/

tool if the appliance/tool has a separate battery pack.

u

  Or run the battery down completely if it is integral and then

switch off.

u

  Unplug the charger before cleaning it. Your charger does

not require any maintenance apart from regular cleaning.

u

  Regularly clean the ventilation slots in your tool/appliance

and charger using a soft brush or dry cloth.

u

  Regularly clean the motor housing using a damp cloth. Do

not use any abrasive or solvent-based cleaner.

u

  Regularly clean the cutting line and spool using a soft

brush or dry cloth.

u

  Regularly use a blunt scraper to remove grass and dirt

from the underneath of the guard.

Protecting the environment

Z

Separate collection. This product must not be

disposed of with normal household waste.
