5

BP B3 AFIB

EN



«

CL

» is displayed when the reading is deleted from the

memory successfully.

How do I evaluate my blood pressure?

The triangle on the left-hand edge of the display

BL

 points at the

range within which the measured blood pressure value lies. The

value is either within the optimum (green), elevated (yellow) or high

(red) range. The classification corresponds to the following ranges

defined by international guidelines (ESH, ESC, JSH). Data in mmHg.

The higher value is the one that determines the evaluation.

Example: a blood pressure value of

140/80

 mmHg or a value of

130/90

 mmHg indicates «blood pressure too high».

Appearance of the Pulse Arrhythmia (PAD)

This symbol

BT

 indicates that certain pulse irregularities were

detected during the measurement. In this case, the result may

deviate from your normal blood pressure – repeat the measure-

ment. In most cases, this is no cause for concern. However, if the

symbol appears on a regular basis (e.g. several times a week with

measurements taken daily) we advise you to tell your doctor.

Please show your doctor the following explanation:



In MAM mode Atrial Fibrillation (AF) will also be checked:

follow the directions in chapter «2.».



If the symbol appears, select MAM mode and measure

again: see details in chapter «2.».

6. Data Memory

This device automatically stores the last 99 measurement values.

Viewing the stored values

Press the M-button

3

 briefly, when the device is switched off. The

display first shows «

M

»

AP

 and «

A

», which stands for the average

of all stored values.

Pressing the M-button again displays the previous value. Pressing

the M-button repeatedly enables you to move from one stored

value to another.



Blood pressure readings with suboptimal cuff fit

AR

-A are

not considered in the average value.



Pay attention that the maximum memory capacity of 99

memories is not exceeded.

When the 99 memory is full, the

oldest value is automatically overwritten with the 100th

value.

 Values should be evaluated by a doctor before the

memory capacity is reached – otherwise data will be lost.

Clearing all values

If you are sure that you want to permanently remove all stored

values, hold down the M-button (the device must have been

switched off beforehand) until «

CL ALL

» appears and then

release the button. To permanently clear the memory, press the

MAM button while «

CL ALL

» is flashing. Individual values cannot

be cleared.



Cancel deletion:

press ON/OFF button

1

 while «

CL ALL

»

is flashing.

7. Battery Indicator and Battery change

Low battery

When the batteries are approximately ¾ empty the battery symbol

AQ

will flash as soon as the device is switched on (partly filled battery

displayed). Although the device will continue to measure reliably, you

should obtain replacement batteries.

Flat battery – replacement

When the batteries are flat, the battery symbol

AQ

 will flash as soon

as the device is switched on (flat battery displayed). You cannot

take any further measurements and must replace the batteries.

1. Open the battery compartment

7

 at the back of the device.

Range

Systolic Diastolic Recommendation

1. blood pressure

too high

≥

135

≥

85

Seek medical

advice

2. blood pressure

elevated

130 - 134 80 - 84

Self-check

3. blood pressure

normal

<130

<80

Self-check

Information for the doctor on frequent appearance of the

Arrhythmia indicator

This device is an oscillometric blood pressure monitor that also

analyses pulse irregularity during measurement. The device is

clinically tested.

The arrhythmia symbol is displayed after the measurement, if

pulse irregularities occur during measurement. If the symbol

appears more frequently (e.g. several times per week on

measurements performed daily) we recommend the patient to

seek medical advice.

This device does not replace a cardiac examination, but serves

to detect pulse irregularities at an early stage.
