Microlife BP B3 AFIB - Инструкция по эксплуатации - Страница 6

4



Connect the cuff to the device by inserting the cuff connector

9

into the cuff socket

5

 as far as it will go.

Selecting standard or MAM mode

Before each measurement, select standard (single measurement)

or MAM mode (automatic triple measurement). In MAM mode,

3 measurements are automatically taken in succession and the

result is then automatically analysed and displayed. Because the

blood pressure constantly fluctuates, a result obtained in this way

is more reliable than when a single measurement is performed.



To select MAM mode, press the MAM button

4

 until the MAM-

symbol

AO

 appears on the display. To change to standard mode

(single measurement), press the MAM-button again, until the

MAM-symbol disappears.



The bottom, right hand section of the display shows a 1, 2 or 3 to

indicate which of the 3 measurements is currently being taken.



There is a break of 15 seconds between the measurements.

A count down indicates the remaining time.



The individual results are not displayed. Your blood pressure will

only be displayed after all 3 measurements are taken.



Do not remove the cuff between measurements.



If one of the individual measurements was questionable, a fourth

one is automatically taken.



AF detection is only activated in MAM mode.

4. Checklist for Taking a Reliable Measurement



Avoid activity, eating or smoking immediately before the

measurement.



Sit down on a back-supported chair and relax for 5 minutes.

Keep the feet flat on the floor and do not cross your legs.



Always measure on the same arm

 (normally left). It is recom-

mended that doctors perform double arm measurements on a

patients first visit in order to determine which arm to measure in the

future. The arm with the higher blood pressure should be measured.



Remove close-fitting garments from the upper arm. To avoid

constriction, shirt sleeves should not be rolled up - they do not

interfere with the cuff if they are laid flat.



Always ensure that the correct cuff size is used (marking on the cuff).



Fit the cuff closely, but not too tight.



Make sure that the cuff is positioned 2 cm above the elbow.



The

artery mark

 on the cuff (ca. 3 cm long bar) must lie over

the artery which runs down the inner side of the arm.



Support your arm so it is relaxed.



Ensure that the cuff is at the same height as your heart.

5. Taking a Blood Pressure Measurement

1. Select standard (single measurement) or MAM mode (automatic

triple measurement): see details in chapter «3.».

2. Press the ON/OFF button

1

 to start the measurement.

3. The cuff will now pump up automatically. Relax, do not move

and do not tense your arm muscles until the measurement

result is displayed. Breathe normally and do not talk.

4. The cuff fit check

AR

 on the display indicates that the cuff is

perfectly placed. If the icon

AR

-A appears, the cuff is fitted

suboptimally, but it is still ok to measure.

5. When the correct pressure is reached, the pumping stops and the

pressure falls gradually. If the required pressure was not reached,

the device will automatically pump some more air into the cuff.

6. During the measurement, the pulse indicator

BM

 flashes in the

display.

7. The result, comprising the systolic

AL

 and the diastolic

AM

 blood

pressure and the pulse rate

AN

 is displayed. Note also the

explanations on further display symbols in this booklet.

8. When the device has finished measuring, remove the cuff.

9. Switch off the device. (The monitor does switch off automatically

after approx. 1 min.).



AF detection is only activated in MAM mode.



You can stop the measurement at any time by pressing the

ON/OFF button (e.g. if you feel uneasy or an unpleasant

pressure sensation).



This monitor is specially tested for use in pregnancy and

pre-eclampsia. When you detect unusual high readings in

pregnancy, you should measure after a short while again

(eg. 1 hour). If the reading is still too high, consult your

doctor or gynecologist.

In pregnancy the AFIB symbol can be ignored.

Manual inflation

In case of high systolic blood pressure (e.g. above 135 mmHg)

,

it can be an advantage to set the pressure individually. Press the ON/

OFF button after the monitor has been pumped up to a level of

approx. 30 mmHg (shown on the display). Keep the button pressed

until the pressure is about 40 mmHg above the expected systolic

value – then release the button.

How not to store a reading

As soon as the reading is displayed press and hold the ON/OFF

button

1

 until «

M

»

AP

 is flashing. Confirm to delete the reading by

pressing the MAM button

4

.
