If the temperature dose not change within an hour, .then the upward or downward
pointing arrow becomes no display. The measured temperature is the taken as the
neutral value from which further prognoses are made.

After you insert the battery

•

The weather station automatically starts receiving transmission from Outdoor Thermo
Sensor for outdoor temperature after new batteries are inserted.

•

The sensor will automatically transmit temperature to the weather station after batter-
ies inserted. Batteries compartment of thermo sensor is locating behind the back
cover, unscrews to open.

•

For having more than one external transmitter (Maximum 3), select the Channel, CH1,
CH2 or CH3 to ensure each sensor is transmitting difference channel inserting batteries.
The channel select switch is at the back of the thermo sensor.

•

Press "TX" button on the thermo sensor unit transmit temperature to the weather station
manually. The weather station gives a "beep" sound if it received the temperature.

•

Press oC/oF button to select Temperature in Celsius mode/Fahrenheit mode.

•

Press "CHANNEL" button to view 3 Channel' s temperature .The sequence is shown as
follow:

•

Press "CHANNEL" button Display the three channels alternatively

•

Hold "CHANNEL" button for 3 seconds to cancel unused channel manually .It will auto-
matically register a new channel again if a new channel is transmitted.

•

Three round arcs which is below the channel digitals' right side, it indicates the intension
of signals for remote sensor. When it has three round arcs, it shows to be strongest sig-
nal, when it has two round arcs, it shows to be common signal, when it has only one
round arcs, it shows very weaker signal.

•

The pointer displayed on the LCD indicates the trend of the outdoor temperature.

indicates the outdoor temperature is increasing.

indicates the outdoor temperature is decreasing.

•

Press oC/oF button ,on the Thermo Sensor unit, to select Thermo Sensor displayed in
Celsius mode or Fahrenheit mode.

Low battery icon

appear at indoor temperature and outdoor temperature row in

particular channel indicating the external transmitter of the channel in low battery sta-
tus.

Note :

Always read users manual carefully before operating the Unit.
The clock loses its time information when the battery is removed.
All Setting Mode will automatically exit in 20 seconds without any adjustment.
When any alarm is activated the backlight must be light for 5 seconds

Number of the week accordance with ISO.

RST02708 13

Outdoor thermo sensor unit registration procedure

Display outdoor temperature

Low batteries indicator

Number of week
