Centek CT-8432 - Инструкция по эксплуатации - Страница 30

30

Problem

Possible reasons

Solution

No image, no sound, no

indicator light

1. The power cord is not plugged

in outlet

2. The power is off

1. Plug the cord into an outlet

2. Turn on the power

The image and sound are

distorted

1. Contrast, sharpness and color

are set incorrectly

2. The color rendering system is

set incorrectly

3. The sound system is not set

correctly

1. Adjust the contrast,

sharpness and color values

2. Install a color rendering

system according to the

broadcasting standards in

the country

3. Install a sound system

according to the broadcasting

standards in the country

The picture is spotted or

with snow

The signal source is weak

or the cable is of bad

quality

Use a good quality cable

There is no image, no

sound and the indicator is

green/blue

The volume is at the

minimum value or the T V is

in mute mode

Adjust the volume level

The cable through which

the signal is transmitted is

connected incorrectly

Connect the signal cable

correctly

Blue screen, AV inscription

There is no input signal

or the video cable is not

connected or connected

incorrectly

Connect the video cable

correctly

The image is fuzzy or

flinches or with black

horizontal stripes (in

PC mode)

The PC image is adjusted

incorrectly

enter the "Screen"

menu, select auto-tune

to perform automatic

calibration and adjust

the phase

PC Image is not entered

No sound

There is no incoming audio

signal or the audio cable is

incorrectly connected

Connect the audio cable

correctly

PC picture with wrong color

The color gamut is

incorrectly adjusted by

the user

Adjust the color settings

or reset the color settings

to factory settings

The HDMI source shows

with snow and pixels

The signal source is non-

standard

Reconnect the HDMI cable

The remote control does

not work

Batteries are incorrectly

installed or their service

life has expired

1. Make sure that the

positive and negative

poles are correctly

oriented.

2. Check if there is contact

between the battery and

the spring

3. Replace the batteries

6. CARE

-

Thorough and regular cleaning can prolong the life of your new TV and save

you from possible malfunctions. Be sure to turn off the power and disconnect

the power cord before starting any cleaning. Clean the appliance only with

a dry cloth.

7.

SPECIFICATIONS

-

Screen size: 32’’ (81 сm), HD ready

-

Resolution: 1366×768

-

Aspect ratio: 16:9

-

Contrast ratio: 3000:1

-

Refresh rate: 60 Hz

-

Voltage: 220-240 V ~50/60 Hz

-

Power consumption: 45 W

-

Audio Output 5 W + 5 W

-

Angle of view (L/R): 170⁰/170⁰

-

ATV Color Systems: PAL/SECAM

-

TV Signal: DVB

-

T/T2/C

-

Inputs and outputs: 2xHDMI, 1xRF, CI, 1xAV, 1xCoaxial

-

TV (RF): Unbalanced 75 ohms

-

Additional options: sleep mode, program list, teletext

8.

DISPOSAL

Upo n expiry of its service life the appliance can be disposed of separately

from ordinary domestic waste. You can turn it over to a specialized electric

and electronic appliance disposal and recycling centre.

9.

CERT IF IC AT IO N DAT A, GU ARANT EE

Т The service life of this item is 10 years since the date of sale to the end

user, provided the item will be used in strict accordance with the present

manual and the applicable technical standards. U pon expiry of the service

life please contact the nearest authorized service centre for suggestions

as to further operation of the appliance. The manufacturing date of the

appliance is integrated into the serial number (digits 2 and 3 - year, digits 4

and 5 - month of manufacture). Guarantee and post-guarantee maintenance

is provided by the General Service C

E NT E R

 OOO «Larina-Servis» (Russia,

Krasnodar), phone: +7 (861) 991-05-42. The address of the facility authorized

with receiving buyer claims, maintenance and repairs is shown on the

website

https://centek.ru/servis

, otherwise refer to the store or other legal

entity, where you have purchased this appliances.

The product has the Certificate of Conformity No.

10.

INFORMATION ABOUT THE MANUFACTURER, IMPORTER

y:

OOO «Larina-Elektroniks».

 Address:

Russia, 350080, Krasnodar, ul. Demusa,

14. Phone: +7 (861) 2-600-900.

DEAR CONSUMER!

The guarantee period for all appliances amounts to 36 months from the

date of sale to the end consumer. With this Warranty Card the Manufacturer

confirms the proper condition of the appliance and undertakes to repair, free

of charge, all defects caused by the Manufacturer’s default.

GUARANTEE MAINTENANCE TERMS

1. The guarantee shall be valid if the following documentation conditions

are observed:

• The original Warranty Card shall be filled out correctly and clearly,

indicating the of appliance model, serial number and sale date, the stamp

of the seller company and signature of its representative shall be available,

as well as the stamps on each coupon and the buyer’s signature in the

Warranty Card.

The Manufacturer reserves the right to reject guarantee maintenance if the

buyer fails to provide the abovementioned documents or if the information

contained therein is incomplete, illegible or ambiguous.

2. The guarantee shall be valid if the following operation conditions are

observed:

• the appliance is used in strict accordance with the present manual;

• the safety rules and requirements are observed.

3. The guarantee does not apply to regular maintenance, cleaning,

installation and setup of the appliance at the owner’s location.

4. The guarantee does not apply in the following cases:

• mechanical damage;

• normal wear of the appliance;

• non-observance of operation requirements or erroneous actions on the

part of the user;

• improper installation or transportation;

• natural disasters (lightning, fire, flood, etc.), as well as any other causes

beyond the Manufacturer’s or Seller’s control;

• ingress of foreign objects, liquids or insects into the inside of the appliance;

• repairs or modifications to the appliance by unauthorized persons;

• use of the appliance for commercial purposes (loads exceeding

normal domestic application), connection of the appliance to utility and

telecommunication networks incompliant with national technical standards;

• failure of the following accessories, if replacement of these is allowed by

design and does not involve disassembly of the appliance:

a) remote control units, rechargeable batteries, replaceable batteries

(power cells), external power supply units and chargers;

b) consumables and accessories (packaging, covers, slings, carry bags,

mesh screens, blades, flasks, plates, supports, grilles, spits, hoses, tubes,

brushes, nozzles, dust collectors, filters, smell absorbers);

• for battery-powered appliances – operation with inappropriate or depleted

batteries;

• for rechargeable battery-powered appliances – any damage caused by

improper battery charging and recharging.

5. The present guarantee is provided by the Manufacturer in addition to

the consumer rights determined by the applicable legislation and does not

limit these rights in any way.

6. The Manufacturer shall not be made liable for possible damage, directly or

indirectly inflicted by CENTEK brand products on people, domestic animals,

the consumer’s or third persons’ property if such damage is inflicted as the

result of non-observance of appliance installation and operation

requirements, deliberate or negligent actions (omission) by the consumer

or third persons, as well as of force majeure circumstances.

7. Service centers will only accept appliances in a clean state (there should

be no food residues, dust and other contamination on the appliance).
