Before you start

4

4

Before you start

product. If the liquid is spilt, it may cause the
fire, electric shock or breakdown.

• Do not install it at the place on the strong

magnetic field or current field. It may cause
break down. This equipment may be observed
deterioration of the picture by electromagnetic
radiation in electromagnetic environment.

• Fasten the wheel of the product or shelf

with wheels when installing this product. If it
moves or is tipped over, it may be damaged.

• Do not place any fire source such as

candlelight close to this product or place it on
this product. If it is tipped over or fallen down, it
may cause damage or fire.

• Do not place the unit into closed space

of TV for better ventilation; it can reduce the
product lifetime. Keep a space at least 10 cm
at above, left, and right of the TV.

• Please place all the signal cords behind of

rear panel.

• Do not overexert or touch the panel when

you convey the product. Do not transfer the
LED TV up or down display direction.

• Do not transport it with the power cord

or the connection cable connected. If you
move this product with the power cord or the
connection cable connected, damaged power
cord, connection cable or connection terminal
may cause fire, electric shock or breakdown.

• 2 persons or more shall transport the

device, which is heavier than 18 kg. If you drop
or tip over the device, it may damage it.

• The temperature of the product’s body

becomes a little higher after a long period use.
This phenomenon indicates that heat exchange
in normal working mode, thus please do not
let children or anyone who is sensitive of
temperature to touch.

All images provided herein are schematic

drawings and may differ from real objects.

Installation

Base installation

Cover a flat stable surface with a soft cloth.

Place the TV unit facedown on the cloth. Insert
the base into the lower back panel of the unit.

Align the base assembly with holes on the

back of the unit cabinet and fasten with 4
screws.

Wall mounting

• For wall mounting the back panel of this

unit is equipped with 4 screw holes (spread
distance

400x200

mm). A VESA wall-mount

bracket should be used for wall mounting (the
bracket is not included and should be acquired
separately). Manufacturer is not responsible
for improper mounting resulting in damage of
the unit.

WARNING

In order to avoid damage, make sure

to  secure  the  unit  on  the  wall

according  to  the  wall  mounting

instruction

.
