Before you start

4

4

Before you start

cups, medicines or any other liquid

containing objects on the unit. Spillages may
cause fire, electric shock or breakdown.

•  Do not install the unit in locations with

a strong magnetic or current field as it may
cause malfunction. Picture deterioration due to
electromagnetic radiation in this environment is
also possible.

•  Do not place any fire source such as

candles close or on this product. If tipped over
or fallen down, it may cause damage or fire.

•  Do not place the unit into closed space

of TV for better ventilation; it can reduce the
product lifetime. Keep a space at least 10 cm
at above, left, and right of the TV.

•  Please place all the signal cords behind

the rear panel.

•  Do not overexert or touch the panel when

carrying the product. Do not transport the LED
TV with the display faced up or down.

•  Do not transport the unit with the power

cord or the connection cable connected as it
may damage the power cord, connection cable
or connection terminal which may cause fire,
electric shock or breakdown.

•  Make sure that 2 persons or more carry

the device heavier than 18 kg. Dropping or
tipping over the device may damage it.

•  The temperature of the product’s body

becomes a little higher after a long period
of use. This indicates that heat exchange
is in normal working mode, thus please do
not let children or anyone who is sensitive to
temperature touch the unit.

All images provided herein are schematic

drawings of real objects and may differ
from their real life images.

Installation

Wall mounting

For wall mounting the back panel of this

unit is equipped with 4 screw holes (4 mm
diameter, 135 mm horizontal spread distance
x 100 mm vertical spread distance). A VESA
wall-mount bracket should be used for wall
mounting (the bracket is not included and
should be acquired separately). Manufacturer
is not responsible for improper mounting
resulting in damage of the unit.

Stand installation

Place the LED TV on a solid flat surface.

Use soft material to place over the front screen
to avoid any damage. First, use the fixing
elements to assemble a stand as shown below.
Fasten with 4 screws. Then align the stand
with the slots in the lower part of the unit and
fix the two parts by 4 screws.

Wall or ceiling mounting implements

must be durable and sufficient enough to
support the weight of the unit.
