Operation

11

11

Operation

position of the image.

•

Vertical Position

: adjust vertical position

of the image.

•

Clock

: adjust the image frequency

manually.

•

 Phase

: adjust the phase manually.

USB operation

General playback information

•  Insert a USB drive into the USB port.

Select USB source and press OK button. The
screen will show a USB playback window, in
which you can select Music, Photo, Movie and
Text contents to play by pressing LEFT/RIGHT
cursor buttons and OK button.

•  USB file systems supported: FAT16, FAT32

(NTFS support is not guaranteed). USB 2.0
version is supported; maximum capacity 2 TB.
For correct and satisfactory operation, licensed
USB devices of well-known brands should be
used. Avoid using USB devices of unknown
brands. Playback of some file formats cannot be
supported.

•  This unit supports playback of video files

with AVI, MKV, MOV, MPG, DAT, VOB, TS,
TRP extensions, with video codecs DIVX,
H264, MPEG-4, MPEGII, XVID and audio
codecs WMA, MP3, DD(AC3).

  The above list of extensions and codecs

is for information only and is not a guarantee
that all files having the above extensions and
codecs sohuld be read by this unit.

•  Some AVI files cannot be played due to

their parameters and recording conditions.
Video files with AVI extension exceeding 2 GB
in size may be played partially.

According to the USB 1.1/2.0 Standard,

usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal

changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warranty cases.

Warning:

 usage of external USB drives

containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.

Operations of file playback

•  Press cursor buttons to select Return

option and press OK button if you want to go
back to the previous menu.

•  In the content menu, press cursor buttons

to select folder, press OK button or HOLD/
button to enter it, then press cursor buttons to
select the file you want to watch or to listen to.
When highlighting the file, the file information
will appear on the right (not available for text
files) and picture will be previewed in the center
(not available for music and text files). Press
OK button or   button to play the selected file.

•  While playback, press OK button; the

bottom of the screen will show playback menu
in which you can select an operation by LEFT/
RIGHT cursor buttons or perform this operation
by pressing OK button. The operations are as
follows:

Play or pause playback

All files

Select previous file

All files

Select next file

All files

Stop plabyack and return to
previous menu

All files

Select repeat playback
mode

All files

Play music in background
mode when photo or text
file is being browsed (you
should select music file first)

and
Text

Show playlist

All files
