Operation

11

11

Operation

keep all the existed channels and add newly
found channels to the end of the channel list.
To stop search, press MENU button; detected
channels will be stored.

•

Manual tuning

: Press OK button to enter

into manual tuning menu:

Channel: select channel number.
Band: select frequency band (VHFH/UHF/

VHFL).

Frequency: adjust the current frequency step

by step.

•

Fine tune

: adjust the current frequency

manually to improve the quality of signal if it is
too week.

•

Sound system

: select the sound system

(DK/BG/I/M).

•

Channel edit

:

Current Channel: select the current channel

number.

Target Channel: select a target channel for

swapping.

Skip: select Current channel number to be

skipped. Select Skip item and select Yes to
confirm. Now this channel will be skipped when
next/previous channels are selected.

Swap: select Current channel and Target

channel to be swapped. Select Swap item and
and select Yes to confirm swapping.

USB operation

General information

  USB file systems supported: FAT32.

2.0 USB version is supported. For correct and
satisfactory operation, licensed USB devices
of famous brands should be used with this unit.
Avoid using USB devices of unknown brands.
Playback of images and music of only JPEG
and MP3 format is supported. The output
capability of the USB port is 1 A.

•  This unit supports playback of video files

with 3GP, AVI, DAT, M2TS, TS, MKV, MOV,
VOB extension, with video codecs H264/AVC,
H263, DIVX, XVID, MPEGI, MPEGII and audio
codecs PCM, DD(AC3), MP3, WAV, WMA.

  The above list of extensions and codecs

is for information only and is not a guarantee
that all files having the above extensions and
codecs sohuld be read by this unit.

•  Some AVI files cannot be played due to

their parameters and recording conditions.
Video files more than 2 Gb having AVI
extension can be played partially.

  According to the USB 1.1/2.0 Standard,

usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warrantee cases.

Warning:

 usage of external USB drives

containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.

File playback

Insert a USB into the USB jack. Press MENU

button, select Media option and press OK
button. The screen will show USB playback
menu:

Multimedia

Movie show
Photo show
Music show
Auto play

•  Video file playback: Select

Movie Show

item and press OK button. Press cursor but-
tons to select a file and press OK button to
start playback. During playback press MENU
button to show playback menu in which you
can select an operation by LEFT/RIGHT cursor
buttons and perform this operation by pressing
OK button. The operations include Play/Pause,
Backward, Forward, Prev., Next, Stop, Repeat
Mode, AB Repeat setting, Playlist, Info., Slow
Forward, Step Forward, Goto Time,
