Operation

7

7

Operation

Remote controller (RC)

1

2
3

4

5
6
7

8

9

10

11

12
13

14

15

24

25

26

27

28

29

31
30

16

17

18

19

20

21

22

23

1. POWER/STANDBY button
2. REC button
3. INFO button
4. NEXT(

)/LIST button

5. PREV.(

)/HOLD button

6. PLAY/INDEX button
7. PAUSE/ZOOM button
8. Number buttons
9. RETURN button
10. VOL+/VOL- buttons
11. Red button
12. SOURCE button
13. F1 (Freeze) button
14. OK button

15. S.MODE button
16. P.MODE button
17. Cursor (UP/DOWN/LEFT/RIGHT) buttons
18. MENU button
19. FAV./Yellow button
20. EPG/Blue button
21. SUBTITLE/Green button
22. MUTE button
23. CH+/CH- buttons
24. PROGRAM LIST button
25. STOP( )/REVEAL button
26. ROTATE/TTX button
27. FORWARD(

)/RADIO button

28. BACKWARD(

)/LANGUAGE button

29. Button not operable
30. L/R button
31. WIDE 16:9 button

Changing the battery

1. Remove the battery compartment cover

on the back of the RC.

2. Insert the batteries into the battery

compartment making sure that the correct
polarity is observed.

3. Install the cover back.

1

2

3

•  Use two AAA batteries for the RC. The RC

should be pointed at remote sensor within 8
meters and within 30 degrees at the left or the
right side.

•  Take the battery out of the RC if it is not

used for a long time.

•  Do not mix new and used batteries or

different types of batteries. Weak batteries can
leak and severely damage the RC.

•  Do not expose the RC to shock, liquids,

and do not place it in an area with high
humidity.
