Operation

11

11

Operation

Advanced

ADVANCED

Lock System
Password
Block Program
Parental Control

•

Lock System

: The feature can prevent

unauthorized operation of the TV set unless
entering a 4-digit password. When Lock
System is on and the system is locked,
you must input the system password when
changing certain parameters. Press the right
number buttons for the password. The default
password is

0000

.

  After a password correction has been

confirmed, please remember it for entering into
the Parental Control menu, all functions can
not be activated until the correct password is
entered. If you forget, the master password of

8899

is still valid.

•

Password

: Set the system password.

•

Block Program

: Block/unblock the

desired programs.

•

Parental Control

: Set the restriction level

of parental control.

USB operation

General playback information

•  Insert a USB drive into the USB port.

Select USB as the source. The screen will
show a USB playback window, in which you
can select Video, Music, Photo and Text
modes by pressing LEFT/RIGHT cursor
buttons and OK button.

•  USB file systems supported: FAT16, FAT32

; maximum capacity 1 TB. For correct and
satisfactory operation, licensed USB devices of
well-known brands should be used. Avoid using
USB devices of unknown brands. Playback of
some file formats cannot be supported.

•  This unit supports playback of video files

with ASF, AVI, MKV, MPG extension, with
video codecs WMV9, DIVX, H263, MPEG-4,
MPEGII, XVID and audio codecs WMA, MP3,
DD(AC3).

  The above list of extensions and codecs

is for information only and is not a guarantee
that all files having the above extensions and
codecs sohuld be read by this unit.

•  Some AVI files cannot be played due to

their parameters and recording conditions.
Video files with AVI extension exceeding 2 GB
in size may be played partially.

According to the USB 1.1/2.0 Standard,

usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warranty cases.

Warning:

 usage of external USB drives

containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.

General operations of file playback

•  Press cursor buttons to select Return

option and press OK button if you want to go
back to the previous menu.

•  In the content menu, press cursor buttons

to select folder, press OK button to enter it,
then press cursor buttons to select the file you
want to watch or to listen to. When highlighting
the file, the file information will appear on the
right and picture will be previewed in the center
(not available for music files). Press OK button
or   button to play the selected file.
