Operation

11

Operation

11

•  OSD Duration: select the period of time

after which the OSD will be hidden.

•  Blue screen: set on or off blue screen

activation when no signal.

•  Restore default: reset the parameters to

initial factory settings.

USB operation

•  Insert a USB into the USB jack. Select

USB source and press ENTER button; or press

USB button on the RC. The screen will show a

USB playback window, in which you can select

Music, Photo, Movie and Text contents to play

by pressing LEFT/RIGHT cursor buttons and

ENTER button.

•  This unit supports playback of video files

with ASF, AVI, MKV, MPG, DAT, M2TS, MP4,

TS, VOB extension, with video codecs WMV9,

DIVX, H263, MPEG-4, MPEGII, MPEGI, XVID

and audio codecs AAC, WMA, MP3, DD(AC3).

Video image resolution should not be more

than 576x720.

  The above list of extensions and codecs

is for information only and is not a guarantee

that all files having the above extensions and

codecs sohuld be read by this unit.

•  USB file systems supported: FAT, FAT32.

2.0 USB version is supported, maximum

capacity is 320 Gb; max. load: DC5V, 500 mA.

For correct and satisfactory operation, licensed

USB devices of famous brands should be

used with this unit. Avoid using USB devices of

unknown brands. Playback of some file formates

cannot be supported.

  According to the USB 1.1/2.0 Standard,

usage of a USB device with power current

consumption exceeding 500 mA is not

recommended without supplementary power

supply. Failure to use supplementary power for

connected USB drives with power consumption

exceeding this value as well as defective

USB drives may cause mechanical or thermal

changes of elements of this unit as well as

failure of internal elements of the USB port.

Such damages are not warrantee cases.

Warning: usage of external USB drives

containing BIN files in the root directory may

cause malfunction of the unit or damage to the

software.

General operations of file playback

•  Press cursor buttons to select Return

option and press ENTER button if you want to

go back to the previous menu.

•  In the content menu, press cursor buttons

to select folder, press ENTER button to enter it,

then press cursor buttons to select the file you

want to watch or to listen to. When highlighting

the file, the file information will appear on the

right and picture will be previewed in the center

(not available for music files). Press ENTER

button or   button to play the selected file.

•  While playback, press INFO button; the

bottom of the screen will show playback menu

in which you can select an operation by LEFT/

RIGHT cursor buttons on perform this opera-

tion by pressing ENTER button.

•  While playback, press   button to pause

or resume playback. Press   button to stop

playback.

•  When you select a file to play, you can

delete the selected file by pressing Red button

on the RC.

•  When playing photo, movie and music

files, you can press REPEAT button to select

the repeat play mode.

•  When playing music files you can press

/

 buttons to fast reverse or forward. You can

press

/

 buttons to select the desired files

manually in normal condition.

•  When playing photo files, you can press

/

 buttons to page up or page down the

file. Press LEFT/RIGHT cursor buttons to

rotate the image.

•  Press EXIT button to stop playback and

return to the previous menu screen.
