COMMON INTERF

A

CE (CI)

AV

Connecting devices

Connecting a CI Card

Component / AV input adapter

This TV is compatible with most video playback

devices. You can connect audio, video and other

devices to it according to this manual and

manuals of other devices.

The TV can be connected to the following

devices: Blueray, Android box, game console,

stereo system, etc.

AV

CI

RF

COAXIAL

SCART

HDMI2

HDMI1(ARC)

USB

Composite audio / video input
Self-module connection port
Antenna connection port
Coaxial audio output
SCART input
HDMI type input
HDMI type input
Input for USB devices

Note:

1. When DVI signal is input to HDMI port, "AV Audio" input will automatically accept audio for HDMI port.
2. Some adapters and devices may not work correctly. transmit the signal in non-standard ways.

1(ARC)

AV

Y

W

R

AV

Y

W

R

AV connector
Yellow - video
White - audio L
Red - audio R

1. The CAM - CI Card Module can be purchased from your local digital cable service provider and can be

provided with information on using the CI Card. If you have any difficulties when working with the CI card,

please contact the service provider.

Due to the constant improvement of the products, the names of individual menu modes, the designation

of some connectors on the connector panel and the place of their application, as well as the performance

of certain ergonomic TV control functions, depending on the software version, may slightly differ from

those described and depicted in this manual. which does not significantly affect the operation of the TV.

module

Connection ports

Port

CI card

EN
