Connection ports

Connecting devices

Connecting a CI Conditional Access Card

This TV is compatible with the majority of video playback devices. You may connect audio, video and other

devices to it according to this manual and manuals of other devices.

The TV can be connected to the following devices: Blueray, Android TV Box, Game console, Audio system,

etc.

L/R

VIDEO

LAN

HEADPHONE

OPTICAL OUT

Composite audio input
Composite video - input
Ethernet - input
Headphone out (3.5mm)
Optical output

DC IN

USB

HDMI

Antenna

CI

Mini AV IN

Input for external power supply 12V 3A
Input for USB devices (500mA)
HDMI type input
Antenna connection port
CAM module connection port
Composite audio / video input

Note:

1. Some adapters and devices may work improperly, as they transmit the signal in non-standard ways.

2. All external devices should be connected when the TV is off.

3. The maximum load on the USB port should not exceed 0.5A.

CAM - a CI Card Module can be purchased from your local digital cable service provider and can be

provided with information on using the CI Card. If you have any difficulties when working with the CI card,

please contact the service provider.

Due to the constant improvement of the products, the names of individual menu modes, the designation

of some connectors on the connector panel and the place of their application, as well as the performance

of certain ergonomic TV control functions, depending on the software version, may slightly differ from

those described and depicted in this manual. which does not significantly affect the operation of the TV.

HD, FHD models

E

th

e

rn

e

t

OPTI

C

A

L

HDM

I3

HDM

I2

V

I

D

EO

L

R

Antenna(75

Ω

)

DC I

N

module

authorization card

slot

12
