Sony KV-SW21M81 / KV-SW21M91 - Инструкция по эксплуатации - Страница 7

7

L

R

2

4

5

(MONO)

WEGA GATE

PROG

9

8

7

6

1

2

3

L

R

R

1

L

Y

C

B

C

R

(MONO)

(MONO)

qg

qa

qs

qd

qf

FM

0

TV front panel

TV rear panel

x

TV top control, front and rear panels

TV top control panel

★

 The button will be labeled as SOUND MODE for KV-SW21M81 only.

Button/Terminal

Function

Page

1

!

Turn off or turn on the TV.

4

2

Remote control sensor.

–

3

Wake Up indicator.

12

3

1

Standby indicator.

4

4

i

Headphone jack.

–

5

t

2

Video input terminal 2.

9

6

PROG +/–

Select program number.

–

7

2

 +/–

Adjust volume.

–

8

t

Select TV or video input.

9

WEGA GATE menu operations

6

,

7

V

,

v

,

B

,

b

Select and adjust items.

13

8

Confirm selected items.

13

9

WEGA GATE

Display or cancel WEGA GATE menu.

13

0

FM

Listen to FM Radio.

22

(KV-SW21M95/
 SW21M91 only)

SOUND MODE

Select sound mode options with a 5-Band Graphic

11

(KV-SW21M81 only)

Equalizer display.

qa

8

Antenna input terminal.

9

qs

T

Monitor output terminal.

10

qd

Component video input terminal.

10

qf

t

1

Video input terminal 1.

9

qg

WOOFER

3D WOOFER terminal.

8

(KV-SW21M95 only)
