Connection

Connection

Connection

4

Antenna input
• Connect an external DVB-T/T2 antenna

(cable) connector to the antenna input RF IN.

  The signal in the block cable antenna

can fail to contain DVB-T/T2 signal due to the
carrier frequency altered by the cable network
operator.

  In order to receive digital air TV signal

use an indoor or outdoor UHF antenna. Specify
the possibility and quality of digital air signal
with your local digital TV service providers. The
absence of a stable TV signal in your area can-
not be a reason for returns or refunds without
an additional test of TV signal reception in your
area.

  To increase the reception quality of

the state digital air television in rural areas or
at significant distances from a broadcasting
center we recomment using individual active
outdoor UHF antennae with a high resistance
factor, and placing them at maximum possible
heights.

Power adaptor input
• Connect the DC power adaptor to this

input and plug it into the electrical outlet.

Loop output

•

Connect the LOOP

OUT

jack to TV's

antenna input using a special adapter (not
included) for supplying an analog TV signal.

HDMI-out

•

If your TV has an HDMI video input,

connect it to an HDMI output of this unit using
a

n

 HDMI cable (included).

Stereo audio output

•

Connect the

left (white) and right (red)

terminals of the stereo audio output to the
corresponding audio inputs on your TV using

4

an RCA cable.

CVBS output

•

Connect the

yellow composite

video output to the composite video input on
your TV using an RCA cable.
