Keep the gas bottle (if used) away from heat sources,

_______________(GB)_____________

including direct sunlight.

INSTRUCTION MANUAL

,*

- Use adequate electrical insulation with regard to the

electrode, the work piece and any (accessible)
earthed metal parts in the vicinity.

WARNING! BEFORE USING THE TORCH READ THE

This is normally achieved by wearing gloves, shoes,

INSTRUCTION MANUAL CAREFULLY.

head coverings and clothing designed for this
purpose and by using insulating platforms or mats.

T O R C H   F O R   T I G   W E L D I N G   D E S I G N E D   F O R

- Always protect your eyes using masks or helmets

INDUSTRIAL AND PROFESSIONAL USE.

with special actinic glass.

    Use special fire-resistant protective clothing and do

not allow the skin to be exposed to the ultraviolet and

1.

GENERAL SAFETY

infrared rays produced by the arc; other people in the

CONSIDERATIONS FOR ARC

vicinity of the arc should be protected by shields of

WELDING

non-reflecting curtains.

The operator should be properly trained to use the torch
safely and should be informed about the risks related to
arc welding procedures, the associated protection

   EXTRA PRECAUTIONS

measures and emergency procedures.
(Refer also to the “IEC TECHNICAL SPECIFICATION or

WELDING OPERATIONS:

C L C / T S   6 2 0 8 1 ” :   I N S T A L L AT I O N   A N D   U S E   O F

- In environments with increased risk of electric

EQUIPMENT FOR ARC WELDING).

shock

-   In confined spaces
- In the presence of flammable or explosive

materials

MUST BE evaluated in advance by an “Expert

supervisor” and must always be carried out in the
presence of other people trained to intervene in
emergencies.

-

Avoid direct contact with the welding circuit: the no-

Technical protection measures MUST BE taken as

load voltage supplied by the welding machine can be

described in 5.10; A.7; A.9. of the  “IEC TECHNICAL

dangerous under certain circumstances.

SPECIFICATION or CLC/TS 62081”.

-

When the welding cables are being connected or

- VOLTAGE BETWEEN ELECTRODE HOLDERS OR

checks and repairs are carried out the welding

TORCHES: working with more than one welding

machine should be switched off and disconnected

machine on a single piece or on pieces that are

from the power supply outlet.

connected electrically may generate a dangerous

-

Switch off the welding machine and disconnect it

accumulation of no-load voltage between two

from the power supply outlet before replacing

different electrode holders or torches, the value of

consumable torch parts.

which may reach double the allowed limit.

-

Do not use the torch in damp or wet places and do

An expert coordinator must use measuring

not weld in the rain.

instruments to determine the existence of a risk and

-

Do not use cables with worn insulation or loose

should take suitable protection measures as detailed

connections.

in 5.9 of the “IEC TECHNICAL SPECIFICATION or
CLC/TS 62081”.

-

Do not weld on containers or piping that contains or

  RESIDUAL RISKS

has contained flammable liquid or gaseous

-  IMPROPER USE: it is hazardous to use the torch for

products.

any work other than that for which it was designed.

-

Do not operate on materials cleaned with chlorinated

solvents or near such substances.

-

Do not weld on containers under pressure.

-

Remove all flammable materials (e.g. wood, paper,

rags etc.) from the working area.

-

Provide adequate ventilation or facilities for the

removal of welding fumes near the arc; a systematic
approach is needed in evaluating the exposure limits
for the welding fumes, which will depend on their
composition, concentration and the length of
exposure itself.

-

Before any maintenance on the torch, let it cool and
disconnect welding machine from mains.

2. CONNECTION

(TAB.1 PAG.7)
