Oursson DH2303D/OR - Инструкция по эксплуатации - Страница 8

14

15

Ingredients

Preparation

Cooking

time

Notes

Fruit (nut, cereal,

vegetable, etc.) bar

Grind fruits and mix them with honey, nuts and/or cereal,

shape into bars and put them onto the trays

5-12 hours

Dry and brittle bars

Jerky (optimal temperature from 38 to 68°С

)

Meat (no fat)

Cut the meat across the fibers. Use brines and marinades

for pre-salting meat pieces, when drying remove fat drops

with a tissue from meat slices

4-6 hours

When banded slices

‘t may crack, but must

not break

Fish (only low fat)

Use special marinades, before dying fish must be washed

of salt

12-14 hours

Fish must be free of

visible wet surfaces,

when pushed, should

not be brittle

Poultry

Use same brines and marinades as for meat; separate the

meat from bones, cut the meat across the fibers.

4 hours

Much harder than beef

Vaporization (optimal temperature 58

°С

)

Fruit juices and

purees

Squeeze juice or puree. Pour on a special substrate,

spread a thin layer and place in the trays

\

To a desired

consistency.

•

Unplug the device.

•

Wash trays in warm water with detergents. Wipe

dry everything.

They can’t be washed in a

dishwasher.

•

Wipe dry the device inside and outside with a

damp cloth. Never immerse it into the water

because of the danger of electric shock.

•

Thoroughly dry all the parts.

CLEANING AND  MAINTENANCE,

Рiс. E

Recommendations on dehydration:

1.

Deep trays can be used to prepare products that need

to be cut in big pieces. For example, meat for jerky or

watermelon.

2.

For a fast drying of the ingredients, set the maximum

temperature. To preserve useful properties of the

ingredients set the temperature below 48

 o

C.

3.

Use tight trays to dry small ingredients.

POSSIBLE PROBLEMS AND SOLUTIONS

Problem

Cause

Solution

Dehydrator isn’t gaining

the temperature and isn’t

pumping air

•  No power supply.

•   Check the outlet, if it is active contact the service center.

Dehydrator pumps

air, but isn’t gaining

temperature

•  Required temperature isn’t set.

•   Set the temperature. If the problem remains contact service

center.

Dehydrator gains

temperature, but isn’t

pumping air

•  Motor stopped.

•

 Immediately turn off the device and remove pieces of food

that could have stuck in the motor. To do this, turn the base

of the dehydrator and shake it several times. If the fan does

not turn on, contact a service center. If liquids are spilled into

the base of the dehydrator, unplug the device and contact a

service center to replace the motor unit.

Products dry slow

•  Trays are filled, or are installed

incorrectly or are damaged.

•   Unload the trays, check if they are installed correctly, replace

damaged once with new. If there are 4 trays installed change

them in the process of dehydration.

Uneven drying of the

products

•   Products or pieces have an

unequal size.

•   Perhaps air flow is blocked.

•  Cut the products into equal pieces and place them evenly.

•  Do not block the air openings with products.

Fan noise

•   Perhaps pieces of food stuck

in the fan.

•  Fan is defective.

•   Immediately turn off the device and remove pieces of food. To

do this, turn the base of the dehydrator and shake it several

times. If the fan still makes noise, contact a service center.

•  Contact a service center.

Specifications

Model

DH1300, DH1304

DH2300D DH2302D

DH2303D

 DH3501D

Power consumption, W

max 400

max 400

max 400

Rated voltage

220-240V~; 50-60 Hz  220-240V~; 50-60 Hz  220-240V~; 50-60 Hz

Class of protection against electrical shock

II

II

II

Storage and transportation temperature

-25°C to + 35°C

-25°C to + 35°C

-25°C to + 35°C

Operating temperature

+5°C to +35°C

+5°C to +35°C

+5°C to +35°C

Humidity Requirements

15-75% without

condensate

15-75% without

condensate

15-75% without con

-

densate

Size of the device, mm

330x330x250

330x330x270

330x330x290

Weight, kg

2,5

2,7

2,9

For information on product certification, see

 http://www.oursson.com/rus/ru/about/partners/certificates/#tab0

or ask seller

for a copy.

PRODUCT CERTIFICATION

*

Products should be stored in dry, ventilated warehouses at temperatures below

 - 25°С.

Reparation  must  be  performed  only  by  a  qualified  personnel  authorized  by  OURSSON AG  service

center.

Company OURSSON AG expresses great appreciation to

you for choosing our products. We have done everything

possible so that this meets your needs, and the quality

corresponds to the best world standards. If your OURSSON

branded product will need maintenance, please contact one

of the authorized service center (hereinafter - ASC). A com

-

plete list of ASC and their exact addresses can be found on

the website www.oursson.com.

Warranty obligations OURSSON AG:

1.

Warranty obligations OURSSON AG, provided ASC

OURSSON AG, apply only to models designed

OURSSON AG for the production or supply and sale wi

-

thin the country where the warranty service is provided,

purchased in this country, certified for compliance with

the standards of this country, and also marked the with

official marks of conformity.

2.

Warranty obligations OURSSON AG operate within the

law on protection of consumer rights and are regulated

by the laws of the country in which they are provided, and

only when the product is used exclusively for personal,

family or household purposes. Warranty obligations

OURSSON AG shall not apply to uses of goods for

business purposes or in connection with the acquisition

of goods to meet the needs of enterprises, institutions

and organizations.

3.

OURSSON AG sets for its products the following terms

of use and warranty periods:

SERVICING

Product name

Terms of

use,  months

Warranty

Period,

months

Microwave ovens, bread

makers, induction stoves

60

24

Product name

Terms of

use,  months

Warranty

Period,

months

Multicookers, kitchen

processors, kitchen machines,

electric kettles, electric grills,

blenders, mixers, meat

grinders, toasters, thermo

pots,  roasters, coffee makers,

steamers, juice makers,

choppers, dehydrators, yogurt

makers, fermenters, mini-

ovens, freezers, refrigerators,

automatic coffee machines

36

24

Kitchen  scales,  siphons

24

24

4.

Warranty obligations OURSSON AG shall not apply to the

following products, if their replacement is assumed and is

not connected with disassembling products:

•  Batteries.

•

Cases, straps, cords for carrying, mounting acces

-

sories, tools, documentation that came with the product.

5.  Warranty does not cover defects caused due to violations

of the rules of consumer use, storage or transportation of

the goods, actions of third parties or force majeure, includ-

ing but not limited to the following cases:

•  If the defect was a result of careless handling, used for

other purposes, violations of conditions and rules of op

-

eration set forth in the instruction manual, including as

a result of exposure to high or low temperatures, high

humidity or dust, traces of opening the device indepen

-

dently and/ or self-repair, mismatch state standards

for power grids, getting liquids, insects or other foreign

objects, substances inside the device, as well as long-

term use of the product in extreme operational modes.

•  If the defect of the product was a result of unauthorized
