8 ENGLISH

FUNCTIONAL

DESCRIPTION

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before adjusting or checking function on the tool.

CAUTION:

Take care not to trap finger(s)

between cleaner and battery as shown in diagram

when loading battery.

Trapping finger(s) may cause

injury.

►

Fig.1

Installing or removing battery

cartridge

CAUTION:

Always switch off the tool before

installing or removing of the battery cartridge.

CAUTION:

Hold the tool and the battery car-

tridge firmly when installing or removing battery

cartridge.

 Failure to hold the tool and the battery

cartridge firmly may cause them to slip off your hands

and result in damage to the tool and battery cartridge

and a personal injury.

►

Fig.2:

1.

 Red indicator

2.

 Button

3.

 Battery cartridge

To remove the battery cartridge, slide it from the tool

while sliding the button on the front of the cartridge.
To install the battery cartridge, align the tongue on the

battery cartridge with the groove in the housing and slip

it into place. Insert it all the way until it locks in place

with a little click. If you can see the red indicator on the

upper side of the button, it is not locked completely.

CAUTION:

Always install the battery cartridge

fully until the red indicator cannot be seen.

 If not,

it may accidentally fall out of the tool, causing injury to

you or someone around you.

CAUTION:

Do not install the battery cartridge

forcibly.

 If the cartridge does not slide in easily, it is

not being inserted correctly.

Battery protection system

The tool is equipped with a battery protection system.

This system automatically cuts off power to the motor to

extend battery life.

The tool will automatically stop during operation if

the tool and/or battery are placed under the following

condition:

Low battery voltage:

The remaining battery capacity is too low and the tool

will not operate. If you turn the tool on, the motor runs

again but stops soon. In this situation, remove and

recharge the battery.

Indicating the remaining battery

capacity

Only for battery cartridges with the indicator

►

Fig.3:

1.

 Indicator lamps

2.

 Check button

Press the check button on the battery cartridge to indi

-

cate the remaining battery capacity. The indicator lamps

light up for few seconds.

Indicator lamps

Remaining

capacity

Lighted

Off

75% to 100%

50% to 75%

25% to 50%

0% to 25%

NOTE:

 Depending on the conditions of use and the

ambient temperature, the indication may differ slightly

from the actual capacity.

Switch action

CAUTION:

Before installing the battery car-

tridge into the tool, always check to see that the

switch trigger actuates properly and returns to

the "OFF" position when released.

To start the tool, simply pull the switch trigger. Release

the switch trigger to stop.

►

Fig.4:

1.

 Switch trigger

Lighting up the lamp

CAUTION:

Do not look in the light or see the

source of light directly.

To turn on the lamp, pull the switch trigger. During the

tool actuating, the lamp turns on.

Release the switch to turn off the lamp.

►

Fig.5:

1.

 Lamp

2.

 Switch trigger

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.
