Karcher WD 6 - Инструкция по эксплуатации - Страница 16

– 8

ATTENTION

Always work with an inserted flat fold filter - during wet
as well as dry vacuum cleaning!

Illustration



Push the suction hose into the connection on the
appliance, it snaps in place.



In order to disconnect it, push down with your
thumb and pull the suction hose out.

Note:

 Accessories, such as suction brushes (optional)

can be directly attached to the connecting piece and
thus connected to the suction hose.
For convenient working even in tight spaces.
The removable handle can be attached between the ac-
cessories and the suction hose if necessary.
See position 17.

Recommendation:

 In order to vacuum the floor, attach

the handle to the suction hose.

Illustration



Connect the handle with the suction hose until it
snaps in place.

Illustration



To remove the handle from the suction hose, press
the notch using your thumb and pull off the handle.

Note:

 Due to removing the handle, accessories can be

directly attached to the suction hose.

Recommendation:

 In order to vacuum the floor, attach

the handle to the suction hose.

Illustration



Put both suction tubes together and connect them
with the handle.

Illustration
For convenient switching between dry and wet dirt:



For vacuuming dry dirt off the floor, use position
with extended brush strips.



For vacuuming water off the floor, use position with
extended rubber lips.



For edges, joints, heaters and hard to reach loca-
tions.

Illustration



To connect the suction hose with an electric tool



Adapt the adapter to the connection diameter of the
electric tool using a knife if necessary.

Illustration



For more flexibility when working with electric tools.

Note

: Can also be used with an adapter.

ATTENTION

Always work with an inserted flat fold filter - during wet
as well as dry vacuum cleaning!

Illustration



Remove the appliance head and take the contents
out of the container.



Turn the container, press in the steering roller in the
openings at the base of the container till the end-
point.



Insert and lock the appliance head.



Clip the holder for the accessory compartment onto
the rear side of the appliance.

Illustration



Connect accessories.

Illustration



Plug in the mains plug.

Illustration



Turn on the machine.

ATTENTION

Work with a dry flat fold filter only.
Check the filter for damage prior to installation and re-
place as necessary.

Illustration



For vacuuming dry dirt an additional filter bag can
be inserted if necessary.

ATTENTION

Only operate the filter cleaning without a filter bag in-
serted, otherwise the filter bag can get damaged.

–

The filling level of the filter bag depends on the dirt
that is sucked in.

–

The filter bag needs to be replaced more frequently
while sucking in fine dust, sand, etc.

–

Clogged filter bags can burst - therefore make sure
to replace the filter bag in a timely manner!

ATTENTION

Vacuum cold ashes only when using a pre-filter.

Order no. basic design: 2.863-139.0, premium design:
2.863-161.0.

ATTENTION

Do not use a filter bag!

Note:

If the container is full, a float closes the suction

opening, and the appliance works at a higher speed.
Switch off the appliance immediately, and empty the
container.



For vacuuming up moisture or wetness pay atten-
tion to the correct floor nozzle setting and connect
the corresponding accessories.

Suction hose with connecting piece

Removable handle

Suction tubes 2 x 0.5 m

Floor nozzle

(with switching lever)

Crevice nozzle

Adapter

Flexible tool hose

Operation

Before Startup

Start up

Dry vacuum cleaning

Information filter bag

Wet vacuum cleaning

16

EN
