18
BLOWING THROUGH
Before blowing through (e.g. dirt depositions in corners), remove upper hook for the power cord (
12
)
located on the upper body (
7
) (
fig. S
). Remove suction hose from the connection socket (
4
) and attach it to
hole in the upper body (
7
) (
fig. T
).
OPERATION AND MAINTENANCE
Disconnect the tool from power supply network before starting any adjustment, maintenance or
repair.
MAINTENANCE AND STORAGE
Ɣ
Regular cleaning ensures longer maximum suction efficiency.
Ɣ
Clean dirt and dust off the vacuum cleaner body with damp cloth. Do not allow water to get inside
the motor.
Ɣ
Empty, clean and dry carefully the tank each time after cleaning wet dirt and liquids. Liquids and wet
dirt speeds up growth of bacteria.
Ɣ
If pleated filter was used, remove and clean with a brush. Frequency of pleated filter cleaning depends
on type and amount of dusts. Replace filter with a new one when necessary. Use only original pleated
filters.
Ɣ
Float and foam membrane must be cleaned and dried thoroughly to avoid growth of mould.
Ɣ
If dust bag was used, replace with a new one when it is full.
Ɣ
Store the vacuum cleaner in dry place, beyond reach of children.
Ɣ
Entrust replacement of power cord and other repairs only to authorized service workshop.
CLEANING AFTER WET OPERATION
Ɣ
When the work is finished, suck 1 to 2 litres of clean water, this will flush telescopic pipe and suction
hose.
Ɣ
Switch off the vacuum cleaner with the switch (
8
) and remove plug from mains socket.
Ɣ
Lift the suction hose so water contained can flow into the tank (
6
).
Ɣ
Unscrew the drain plug (
9
) to empty the dirty water from the tank.
Ɣ
Disconnect the suction hose, release fixing clamps (
3
) on both sides of the device and remove upper
body (
7
).
Ɣ
Clean the tank, leave to dry.
STORAGE
Special incisions on the wheels support (
10
) allow to put the vacuum cleaner accessories in them for
convenient storage and allow convenient changes during operation.
All defects should be repaired by service workshop authorized by the manufacturer.
TECHNICAL PARAMETERS
RATED PARAMETERS
Workshop vacuum cleaner
Parameter
Value
Supply voltage
230 V AC
Power supply frequency
50 Hz
Rated power
1500W
Max. receiver power
2000 W
Height
840 mm
Outside diameter
340 mm
Tank total capacity
40 l
Tank useful capacity
32 l
Length of suction hose
2 m
Diameter of suction hose attachment
35 mm
