Installation
After removing the machine from the packaging, proceed
as follows:
On the back of the machine
1) Unscrew the centre brace A, the two side screws C
and remove the transverse bracket D and the relevant
plastic spacer.
2) Unscrew the 2 B braces and remove them. This will
cause 2 plastic spacers to fall into the machine.
3) Tilt the machine forward and remove the above-
mentioned plastic spacers.
4) Cover the holes using the caps enclosed
in the instructions envelope.
5) Fix the sheet of corrugated material on the
bottom as shown in picture.
6) Level the machine using the two adjustable rear feet.
C
B
B
A C D
69
Appliance complies with European Directive 89/336/EEC, 73/23/EEC and subsequent
amendments.
Technical data
■
Max. load of dry laundry
■
Water pressure
Measurements
■
Width
■
Depth
■
Height
NB: For specifications regarding electrical data, see the data panel on the front of the washing
machine (porthole area).
5 kg
(0,5 ÷ 10 bar)
0,05 ÷ 1 MPa
60 cm
40 cm
85 cm
Customer Service
The appliance is covered by a certificate of guarantee which allows you free use of the Candy
Technical Support Service. Remember to send off the guarantee certificate for validation
within 10 days of the date of purchase.
You should retain the receipt issued by the retailer when you purchased the machine to show
to the call out engineer, should you need to consult one.
If your washing machine shows signs of a defect or is not working properly, before you contact
GIAS Service we recommend you carry out the checks detailed on page 66 within the Trouble
shooting section.
If the problem with the machine persists after completing all the recommended checks, please
dial the GIAS Service number on the rear cover of this manual.
For the cost of a telephone call, you will be connected directly to GIAS. It is important you tell
the GIAS advisor your product’s model number and serial number, which you will find on the
rating label (16 characters, beginning with the number 3), found on the front of the washing
machine (door area). By doing this, your enquiry will be responded to more efficiently.
68
Fig. 2
Note: we recommend you keep the transverse bracket,
braces and screws to immobilise the machine for future
transit. The Manufacturers will not be responsible for any
possible damage to the machine caused by not
following the rules relating to releasing the mechanism.
The user is responsible for all costs of installation.
