5

ASSEMBLY

1.  First, make sure the rubber flap underneath the upper container is pushed inside the juice

spout tube (fig A), then fit the upper container onto the motor base (fig B).

2.  Insert the filter you want to use into the upper container (fig C). The coarse filter allows more of

the pulp to mix with the extracted juice.

3.  Insert the grinding head into the upper container (fig D).  You may have to rotate the grinding

head slightly until it fits over the hexagonal drive shaft correctly. Press the grinding head all the

way down. If you don’t, you won’t be able to fit the upper container cover at the next step.

4.  Align the upper container cover

d

mark with the

 u

mark on the motor base (fig E).

5.  Rotate the upper cover clockwise until the

B

 mark on the upper cover is aligned with the

u

mark on the motor base (fig F).

6.  Flip the upper container cover latch up (fig G).

7.  Insert the pusher (fig H).

8.  Place the pulp container under the pulp outlet, then position the juice collector under the juice

spout and open the juice spout cover (fig J).

USING - JUICING

Prepare the ingredients before use.

•

Buy organically grown produce whenever you can.

•

Use good quality, fresh, ripe fruit and vegetables. Soft vegetables or overripe fruit can make the juice

thick and cloudy.

•

Wash all fruit and vegetables. Use a brush on the harder ones. Remove the outer leaves on non-

organic produce. Peel any non-organic or waxed fruit or vegetables. Cut out and discard bruises and

blemishes as these may affect the taste of the juice.

•

Bunch up leafy greens, parsley, wheat grass, bean sprouts, etc. into a small tight ball and push it

down the tube with the pusher.

•

Cut fibrous ingredients into slices 3-5 cm long by 1.5 - 2 cm thick.

•

Cut longer ingredients such as celery into 3-5 cm pieces.

•

Remove stones from fruit like peaches, plums, mangoes, etc.

•

Peel hard skinned ingredients.

•

Never process ingredients which have a high oil content as this can damage the grinding head.

•

Never process hard ingredients such as coconut which will damage your juicer.

•

Don’t juice anything strong or pungent, like onions or garlic. No matter how well you clean your

juicer, you’ll never get rid of the taste.

1.  Check that the appliance is switched off (

O

).

2.  Put the plug into the power socket.

3.  The switch has three positions: O, I,and

R

 . O is off. I is on.

R

 operates your juicer in the reverse

direction and is only used if something becomes stuck. Never move the switch directly from

I

 to

R

or vice versa. Always stop your juicer by switching to

O

 before changing the operating direction i.e. I

to O to

R

 .

4.  Turn the appliance on (I).

5.  Remove the pusher and drop the ingredients down the tube. Do not feed ingredients too fast and do

not load too many ingredients at once.

6.  Replace the pusher and use it to gently push the ingredients down the tube.

7.  Once finished, turn off your juicer (O).
