25

EN

DESCRIPTION

SAFETY SYSTEM

BEFORE FIRST USE

USING THE APPLIANCE

A

Pusher

B

Feeding tube

C

Cover

D

Sieve

E

Juice collector

F

Pouring Spout with anti-drip system

G

Pulp container

H

Locking Handles

I

Control button

J

Motor unit

K

Drive shaft

L

Anti-slip feet

To start the juicer, the cover (C) must be fitted correctly (Fig. 2) and the clamps properly locked
(Fig. 4).
At the end of a cycle, turn the control button to “0” and wait until the sieve (D) stops completely
before removing the cover (C).

We recommend that you wash the removable parts (A, B, C, D, E, G) before the first use (see
section “Cleaning and care”).
Unpack the appliance and then place it on a solid, stable worktop, remove the cover (C) and take
out the protective card on the sieve (D).

• Place the pulp container in the correct position (see Fig. 1)
• Place the juice collector (E) on the body of the appliance (see Fig. 2).
• Place the sieve (D) in the juice collector (E). Ensure that the sieve is properly clipped onto the

drive shaft (K) (see Fig. 2).

• Fit the cover (C) on the appliance in order to have the pulp evacuation exit to the rear

(see Fig. 3).

• Lock the two handles (H) on the cover (C). You will hear an audible “click” (see Fig. 4).
• Slide the pusher (A) into the feeding tube (B) aligning the groove on the pusher with the small

ridge in the feeding tube.

• Place a glass under the pouring spout (F) in front of the appliance

(see Fig. 5).

• Make sure the spout is opened to let the juice flow.
• Plug in the appliance.
• To start the appliance, use the control button (I).
• Cut the fruits or vegetables into pieces if necessary after removing the stones.
• Insert the fruits or vegetables through the feeding tube (B).
• The fruits and vegetables must be inserted only while the motor is running.
• Do not press too hard on the pusher (A). Do not use any other utensil. NEVER push food with

your fingers.

• When you have finished, stop the appliance by turning the control button (I) to 0 and wait

until the sieve (D) stops completely.
