ENGLISH

2

ATTENTIONS

1.  This machine is unavailble for the weakness,

unresponsive or psychopathic perosn(including

children), unless under the direction or help

from the person who have the responsibility for

security. Children should be overseen, so it can

be testified that they are not playing with it.

2.  Before using, put this machine on a stable and

even table board, operate according to the above

methods.

3.  Before juicing, first confirm juicing net and rotor

clutched in position, and no hard contact between

juicing net cutter and transparent cover. Put the

transparent cover on, fasten tight the handle,

then turn on the machine.

4.  Before being used, the motor works in running-in

phase, there may be slight peculiar smell and

spark, this is normal, after the motor works

for some period, the above phenomenon will

disappear.

5.  During juicing, make sure there is not too full

juice and residue in the middle seat and residue

cup, if too full, please cut off power supply, clean

up, then use again.

6.  During using, do not open the cup cover. In

case power supply is on, do not put hand or any

ware into the mixing cup or feed port, otherwise,

harmful accident may occur or this machine may

be damaged.

7.  In order to prolong service life of this machine,

over-temperature protective device is mounted

in the motor. If the motor works for a long time

or overloaded, when over warning temperature,

power supply will automatically cut off. After the

motor stops, pull out plug of power supply, wait

for the motor to cool  (about for 30 min), use

again.

8.  During operating, please do not leave, never let

children operate this machine.

9.  When this machine works in mixing, mincing or

grinding conditions, no-loaded or over loaded

work is strictly prohibited.

10. After operation, do not pour the food out until pull

out the plug of power supply.

11. Cutters are very sharp, in order to avoid danger,

when cleaning a cutter, please put the cutter

under water tap for washing, do not wash it with

hand.

12. This machine must not be used for others beyond

regulated purposes.

13. In case of damaged power supply cord, in order

to avoid danger, replacement must be performed

by the manufacturer or its service department or

similar professional persons.

MAINTENANCE AND CLEANING

1.  This machine shall be often used, so as to keep

the motor dry and clean.

2.  If not using for a long time, please store this

machine at a dry and well-ventilated place so

as to prevent the motor from being damped and

going moldy.

3.  No washing the main machine. When cleaning,

only wipe with wet cloth. Other components may

be washed directly with water, such as pushing

bar, cover, middle seat, residue cup, juice nozzle

cover.

TECHNICAL DATA:

220-240V • 50Hz • 800W

Environment friendly disposal

You can help protect the environment! Please

remember to respect the local regulations:

hand in the non-working electrical equipments to an

appropriate waste disposal center.

JUICE EXTRACTOR

Please read all instructions carefully before using

DIAGRAM OF NAME AND POSITION

OF MAIN COMPONENTS

1.  Pushing bar

2.  Transparent cover

3.  Juicing net

4.  Middle ring

5.  Handle

6.  Residue barrel

7.  Main machine

8.  Juicer jug

PERFORMANCES

1.  For the juicer with large diameter, entire apple

or pear can be put in for juicing, no cutting apart

needed, easy and quick.

2.  Design is fine, simple, and beautiful, with

combined structure, easy to operate and clean.

3.  High speed electric motor with overheating

protection is adopted, high efficiency, time saving,

energy saving, high service life of the motor.

4.  Safety lock unit for switching is specially

designed, in order to make sure safety and

reliability in use.

ATTENTION BEFORE USING

1.  This machine is set with safety unit, when the

handle does not fasten the cover or the cutter

seat is not fastened, the motor cannot turn, so as

to ensure safety for the user.

2.  When disassembling or assembling the juicer,

press the upper of feed port of the cover with

your hand, then force the handle to slide in or out

of cover slot.

3.  When disassembling juicing net, first remove the

cover and residue barrel, then turn the middle

ring up to 30 degrees by holding juicing nozzle

with your hand, and take up, the juicing net will

automatically leave the rotor.

4.  In order to avoid damage, before using, first

check power supply for compliance with rated

voltage .

5.  Clean all parts able to disassemble (refer to the

section of „maintenance and cleaning“).

6.  When assembling, please carefully read

the diagram of „name and position of main

components“.

7.  Please carefully read the „attentions“ before

using.

JUICING

1.  Before using, please confirm the button switch

of the main machine in stop state, in this way,

in case assembly is not completed, starting the

main machine can be avoided, so unnecessary

damage for persons or property avoided.

2.  Before juicing, first confirm juicing net and rotor

clutched in position, and no hard contact between

juicing net cutter and transparent cover. Put the

transparent cover on, put the handle into the

cover slot, then turn on the machine.

3.  For using, assemble according to the diagram of

„name and position of main components“. Turn

on power supply, press switch to let the machine

run no-load for 5 sec. Put prepared vegetable

or fruit into feed port of the juicer, press with the

pushing bar, evenly, hard and slowly, juice of the

vegetable or fruit can be found, original, fresh,

good for health.

4.

Note:

when pressing food with the pushing bar,

force shall be even or indirect, pressing force

shall not be more than 1 kg, no too sudden force,

otherwise, juicing effect will be reduced.

OPERATING TIME

This machine is designed with button switches of O

grading, I grading, II grading (O for stop, I for weak

grading, II for strong grading). For juicing, select

strong grading, for operating time, after operating for

1min, stop for 1min, then use again.

After the above operation is performed for three

times, stop for 15 min, do not operate until the motor

is cooled, in this way, service life of this machine

will be prolonged, the machine will serve you more

efficiently.
