3-7
E
➜
Press
[Enter]
MOTION DET
In MOTION DET, you can set the Motion Detection function, Motion Detection
Sensitivity, and the Area of Motion Detection. If the Motion Detection function
is set, the movement of an intruder can be detected. When motion is detected,
it sets off the Alarm signal of the Controller.
(CAMERA SET)
CAMERA ID
OFF
V-SYNC
INT
COLOR/BW
COLOR...
MOTION DET
ON...
ZOOM SPEED
3
DIGITAL ZOOM
OFF
DISPLAY ZOOM
OFF
DISPLAY P/T
OFF
EXIT
QUIT
(MOTION DET)
AREA
USER...
SENSITIVITY L ---|--- H
RET
3-6
BW
: The IR Filter is OFF and the screen is black and white.
(Sensitivity to low light is increased to a level comparable to a black
and white camera.)
Select BW and press [ENTER] and the additional menu to select
BURST ON/OFF will appear.
AUTO
: Select to automatically switch between the COLOR mode and BW
mode depending on the amount of light. In low light conditions, the
IR Filter is turned OFF and the sensitivity to low light is increased
by switching to the BW mode, but in bright light conditions, the IR
Filter is turned ON and the sensitivity is decreased by switching to
the COLOR mode.
Select AUTO and press [ENTER] and the additional menu to select
BW LEVEL and DURATION will appear.
- BURST ON
: The color burst signal is output together with black and white
composite video signal.
- BURST OFF
: The color burst signal is not output.
- LEVEL
: You can set the brightness level that changes from COLOR mode
to BW mode in 3 steps : LOW, MEDIUM, and HIGH.
- DURATION
: Set the HOLDING time for switching between COLOR and BW
mode depending the changes in the amount of light. You can set
the HOLDING time to 10sec (S), 30sec, 60sec, or 300sec( L).
➜
Press
[Enter]
(CAMERA SET)
CAMERA ID
OFF
V-SYNC
INT
COLOR/BW
AUTO...
MOTION DET
OFF
ZOOM SPEED
3
DIGITAL ZOOM
OFF
DISPLAY ZOOM
OFF
DISPLAY P/T
OFF
EXIT
QUIT
❈
In AUTO mode, AGC will be displayed as “---“. You can’t adjust the
settings manually.
Caution :
If you use an infrared light source while in AUTO mode, AUTO
switching malfunction and camera AF malfunction may occur.
(AUTO)
BURST
ON
LEVEL
LOW
DURATION S --|---- L
RET
COLOR/BW
In the COLOR/BW menu, you can switch ON or OFF the IR (infrared) Filter.
In a poor illumination environment, the IR filter is turned off in the BW mode the its
sensitivity increases as high as a black and white camera. On the other hand, the
IR filter is turned on and the sensitivity decreases in the COLOR mode.
COLOR
: The IR Filter is ON and the screen is normal. You can press the
[Enter] key to set the COLOR GAIN LEVEL. And when the AGC
function is on, you can set the AGC COLOER LEVEL.
➜
Press
[Enter]
(COLOR)
GAIN (0)I--------
AGC COLOR
(0)----I----
RET
(CAMERA SET)
CAMERA ID
OFF
V-SYNC INT
COLOR/BW COLOR
…
MOTION OFF
ZOOM SPEED
3
DIGITAL ZOOM OFF
DISPLAY ZOOM OFF
DISPLAY P/T
OFF
EXIT QUIT
