User Guide

3

User Guide

1. Overview

CCTV COLOR DOME CAMERA are the monitoring
cameras incorporated with the recent CCD that
provides the best monitoring function in connection
with the CCTV system equipment.

■

Number of CCD pixels

• SCC-B5300(G)

: 270,000 pixels

• SCC-B5300(G)P : 320,000 pixels
• SCC-B5301(G)/SCC-B5303(G)/

SCC-B5305(G)

: 410,000 pixels

• SCC-B5301(G)P/SCC-B5303(G)P/

SCC-B5305(G)P : 470,000 pixels

■

Power supply

• DC 12V/AC 24V

■

Automatic function and special function

• ATW
• BLC
• AGC
• ELC(Electronic shutter iris)

❈

COLOR ROLLING may occur when you use this camera in a
mechanical fluorescent light which is equiped with Manual IRIS
and is set to ELC mode in the ALC/ELC mode setting menu.
In that case, input AC power. (Auto changing Linklock Mode)
(NTSC : 60HZ  PAL : 50HZ)

❈

If you want to use Internal mode instead of Line Lock mode,
apply DC power. Internal mode provides better picture quality
than Line Lock mode.

☞

COLOR ROLLING is the problem that color on the monitor
screen changes non-periodically. This happens when White
Balance is not fixed, becouse a mechanical fluorescent light
flickers when it’s cycle is the same to the cycle of the power
frequency.

E

Contents

1. Overview  ....................................................................... 3

2. Component Name ........................................................ 4

3. Function of Each Component  ................................... 5

4. Installation ..................................................................... 6

Check what is inside the package  ..................... 6

Notes on installation and usage .......................... 6

Cable connection ........................................................7

5. Specifications ............................................................... 9
